14 | ni.com | NI Digital System Development Board User Manual
MIO 501 1.8 V Peripherals
Pin ENET 0 SDIO 0
16 TXCK
17 TXD0
18 TXD1
19 TXD2
20 TXD3
21 TXCTL
22 RXCK
23 RXD0
24 RXD1
25 RXD2
26 RXD3
27 RXCTL
28-39 Unconnected
40 CCLK
41 CMD
42 D0
43 D1
44 D2
45 D3
46 Unconnected
47 CD
48-51 Unconnected
52 MDC
53 MDIO
