Native Instruments TRAKTOR KONTROL Z1 User Manual

5.4.1 MAIN Knob
The MAIN knob located on the top panel
▪ The MAIN volume knob adjusts the volume of the Z1's MAIN OUT located on the Z1's
rear panel.
5.4.2 GAIN Knobs
A Deck's GAIN knob on the top panel.
These knobs control both TRAKTOR's User-Gain level and the Z1's internal direct gain simulta-
neously. Note that these knobs only control the gain of Decks A and B.
It is not possible to control the channel gain of Tracks C and D directly from the Z1.
5.4.3 EQ (HI, MID, LOW)
Just below the GAIN knob at the top of each of the Z1's channels, you will see three EQ knobs
(HI, MID, and LOW). The Z1's EQ section gives you a fast and easy way to adjust for frequency
imbalances.
TRAKTOR KONTROL Z1 Hardware Reference
Top Panel
TRAKTOR KONTROL Z1 - Manual - 25
