Page 2-26 CL40 Antenna Technical Instruction Manual
Issue 3.0 Section 2 Preparation for Use and Installation
Table 2-3: Loading Coil Configuration versus Frequency (Top Loading Kit only)
Freq
(kHz)
Configuration
L1A
(in)
L1A
(out)
L1B
(in)
L1B
(out)
190-200 series 1 15 4 15
201-215 series 1 14 5 15
216-230 series 1 13 6 15
231-245 series 1 11 7 15
246-260 series 1 11 7 14
261-275 series 2 10 7 14
276-290 series 2 9 7 14
291-305 series 2 8 7 14
306-320 parallel 1 20 1 19
321-335 parallel 2 19 1 18
336-350 parallel 1 17 2 17
351-365 parallel 2 17 3 17
366-380 parallel 1 16 4 16
381-395 parallel 2 15 4 16
396-415 parallel 2 14 4 15
416-435 parallel 2 14 4 14
436-460 parallel 2 13 5 14
461-480 parallel 2 12 5 14
481-500 parallel 1 11 6 14
501-570 parallel 1 9 7 14
571-625 parallel 2 8 8 14
626-675 parallel 2 8 9 14
676-750 parallel 1 7 10 14
751-825 parallel 2 6 10 14
826-900 parallel 1 6 11 14
901-975 parallel 1 5 11 14
976-1025 parallel 2 5 11 14
1026-1150 parallel 1 5 12 14
1151-1200 parallel 2 5 12 14
1201-1250 parallel 1 4 12 14
1600-1800 parallel 2 3 12 14
