Page 3-2 CL40 Antenna Technical Instruction Manual
Issue 3.0 Section 3 Parts List
Table 3-1: Mechanical Parts List - CL40 Antenna (Nautel # 199-9000-04)
ITEM # NAUTEL # DESCRIPTION QTY
2 - Not Used 0
3 199-9015-01 Radial Connector Cable Assembly 1
4 199-9036-12 Bonding Lead Assembly 6
5 199-9011 Radial Mounting Plate 1
6 199-9010 Radial Mounting Ring 1
7 199-9012 Radial 6
8 WPS03 Wire, #2 ACSR 6 ft.
9 199-9036-19 Vertical Radiator Assembly 6
10 199-9036-17 Bonding Lead 1
11 199-9007-04 Mast Insulator Assembly, Metal Shroud 1
12 199-9055-05 Upper Mast Splice 2
13 - Not Used 0
14 199-9036-11 Ground Wire Assembly 1
15 199-9058-01 Lifting Bracket 1
16 199-9036-01 Downlead Assembly 1
17 199-9055-04 Lower Mast Splice 2
18 199-9044 Downlead Insulator Assembly 2
19 199-9034-02 Winch Assembly 1
20 199-9009-02 Clamp Assembly (Bottom) 1
21 199-9009-03 Clamp Assembly (Top) 1
22 199-9030-** ATU Mounting Brackets (Nautel # depends on the ATU) 2
23 199-9064-03 Hardware Kit, CL40 (see Table 3-2) 1
24 HPS21 Rod, Ground, 5/8 Dia. X 6 ft, Galvanized 1
25 HPS10 Connector, Ground Rod 1
26 199-9040 or 9041 Anchor Post (Nautel # depends on type of anchoring) 1
27 199-9035 Ground Plane, 6 Radials (Optional) 1
or
27 199-9035-01 Ground Plane, 60 Radials (Optional) 1
28 199-9008-01 Lightning Bypass Bracket Assembly 1
29 199-9131 Mounting Bracket Assembly 4
30 199-9050-03 Lower Mast Section, Lower Half 1
31 199-9050-04 Lower Mast Section, Upper Half 1
32 199-9051-05 Upper Mast Section, Lower Half 1
33 199-9005-03 Upper Mast Section, Upper Half 1
34 - Not Used 0
35 199-9130-01 Mount Bracket Back Plate 2
36 199-9036-15 Ground Wire Assembly 1
37 199-9036-16 Wire Assembly (Bonding Lead 36”) 1
A1 NAT42A CL40 Loading Coil Enclosure 1
