CL40 Antenna Technical Instruction Manual Page 3-3
Section 3 Parts List Issue 3.0
Table 3-2: Hardware Kit - CL40 Antenna (Nautel # 199-9064-03)
ITEM # NAUTEL # DESCRIPTION QTY
40 HPSA45 U-Bolt, 18-8 Stainless for 3/4 Pipe 6
41 HM06 Washer, Plain, 1/4 Stainless Steel 30
42 - Not Used 0
43 HH25 Screw, Hex, 1/4-20 x 2, Fully Threaded, Stainless Steel 6
44 HL18 Nut, Lock, 1/4-20 Stainless Steel 22
45 HPSA46 Clamp, Hose, 9/16 to 1-1/4 All Stainless 6
46 HPS104 Bolt, Split, Copper, #12 SOL to #8 AWG STR 6
47 HPSA47 Clamp, Hose, 2-5/16 to 3-1/4 All Stainless 7
48 HPS145 Eyebolt, Shoulder, Q277, 5/8-11 x 4-1/2 Lg, Hot Dip Gal 1
49 HPS18 Nut, Hex, Galv, 3/8-16 20
50 HPS31 Washer, Split, Galv 3/8 25
51 HY32 Washer, Flat, Galv 3/8 65
52 HPS146 Eyenut, 5/8-11, Hot Dipped Galv 1
53 HQ18 Adhesive, Silicone Seal RTV Clear (3 oz tube) 1
54 - Not Used 0
55 HPSA49 Bolt, Hex, 3/8-16 x 5, Hot Dipped Galv, Grade 2 1
56 HY67 Bolt, Hex, 3/8-16 x 1, Galv, Grade 2 1
57 HPSA74 Bolt, Heavy Hex, 5/8"-11x 6" lg Hot Dip Gal 6
58 HPSA51 Bolt, Carriage, 3/8-16 x 6, Hot Galv 8
59 HH33 Bolt, Hex, 3/8-16 x 1, Stainless Steel 4
60 HPSA72 Bolt, Heavy Hex, 5/8"-11x4-1/2 LG Hot Dip ASTM A325 4
61 HPSA48 Clamp, Hose, 3-5/16 to 4-1/4 All Stainless 1
62 - Not Used 0
63 HPS144 Washer, Lock, Galv 20
64 HPS142 Nut, Heavy Hex, 5/8-11, HotDip Galv 20
65 HPS143 Washer, Flat, Galv 5/8 50
66 HPSA73 Bolt, Heavy Hex, 5/8"-11x5” lg, Hot Dip ASTM A325 4
