Page 3-4 CL40 Antenna Technical Instruction Manual
Issue 3.0 Section 3 Parts List
Table 3-3: Ancillary Kit - CL40 Antenna (Nautel # 199-9072)
ITEM # NAUTEL # DESCRIPTION QTY
2 199-9073 Wire Assembly 1
3 199-9073-01 Wire Assembly 2
4 199-9073-02 Wire Assembly 2
5 199-9073-03 Wire Assembly 2
6 199-9073-04 Wire Assembly 2
7 199-9073-05 Wire Assembly 2
8 199-9073-06 Wire Assembly 1
9 199-9073-07 Wire Assembly 1
10 HY66 Hex Key, Long Arm, 5/32 1
11 HMW02 Washer, Plain, 1/4 Stainless Steel 20
12 HMN02 Nut, Hex, M3 x 0.5 20
13 HMW32 Washer, Split, M3 20
14 HMSP09 Screw, Pan, Phil, M3, x 0.5 x 8LG 20
Ancillary kit parts are labelled by Nautel #, not by Item #
Table 3-4: Top Loading Kit - CL40 Antenna (Nautel # 199-9085-01)
ITEM # NAUTEL # DESCRIPTION QTY
2 199-9077 Top Load Guy Wire Section 'A' 3
3 199-9078 Top Load Guy Wire Section 'B' 3
4 HAB116 Insulator, Deadend/Suspension 3
5 HPSA48 Clamp, Hose, 3-5/16 to 4-1/4 All Stainless 6
6 HPSA70 Anchor Rod, 5/8” Dia, 77” Len 3
7 - Not Used -
8 HPS21 Rod, Ground, 5/8 Dia. X 6 ft, Galvanized 3
9 HPS10 Connector, Ground Rod 3
10 HPSA47 Clamp, Hose, 2-5/16 to 3-1/4 All Stainless 1
Table 3-5: Guy Wire Kit - CL40 Antenna (Nautel # 199-9087)
ITEM # NAUTEL # DESCRIPTION QTY
2 199-9079 Guy Wire Assembly 3
3 HPSA71 Anchor Rod, 3/4” Dia, 84” Len 3
4 HPS21 Rod, Ground, 5/8 Dia. X 6 ft, Galvanized 3
5 HPS141 Connector, Ground Rod, 5/8”, 8AWG-1/0 3
6 HPSA61 Clamp, Hose, 3-3/4” min to 4-5/8” max All Stainless 1
7 HPS134 Washer, Flat, Galv 3/4 3
8 HPS135 Washer, Lock, Galv 3/4 3
