NV10/NV7.5 Operations and Maintenance Manual Operating the transmitter
Page 2-4 Issue 3.4 2016-08-03
2. On your router or firewall software, open ports 3501 (3501 is factory default, use
corresponding other port if changed) and 80 and close (restrict access to) all other ports. If
you are using RDS data, open port 7005. If you are using SNMP, open ports 161 (Agent)
or 162 (Traps).
3. When properly configured as noted above, the login menu (see Figure 2.3 on page 2-9) will
appear in your web browser when IP address is accessed. Your IP address and any login
messages appear in a box at the top, beside the logo, and the current AUI software version
number appears along the bottom of the login window.
4. Log in to the AUI by entering the appropriate parameters in the login window.
•In the Language field, press the down-arrow to review a drop-down menu displaying
the available language options, and select one.
•In the User field, enter the username. Default is “Nautel”.
•In the Password field, enter the password. Default is blank.
• Press Submit to accept your login parameters and display the AUI home page
(Figure 2.6 on page 2-15). Note: The opening screen (the Home page) will have the lay-
out from the previous login session.
Note:
The Nautel AUI is factory configured with a default login username and
password. Nautel recommends that you change the password to improve overall
system security. See Changing the password on page 2-90.
Note:
If you do not have a user account, it must be set up by an existing user with proper
permissions. See Adding an account on page 2-89.
Note:
If no login attempt is made after 60 seconds, a timeout feature will be activated
and the web browser will be need to be refreshed in order to attempt another login.
