Nautilus MX3-500 - Pressure Regulator; Pump

37
ITEM
DESCRIPTION
QTY
PART NUMBER
1
KIT A PLUNGER & SEALS
1
PT054
2
KIT B VALVES & O
-
RINGS
1
PT055
NS
KIT C CAM &
BEARING
1
PT056
3
MANIFOLD
1
4
PUMP HEAD
2
5
STUFFING BOX
2
6
CRANKCASE
1
7
PLUNGER GUIDE
2
8
HEAD BOLT
6
9
MOUNT BOLT
4
10
WASHER FLAT M6 STAINLESS STEEL
10
NS
PUMP COMPLETE
-
WITH MOTOR
1
AP52
NS
PUMP COMPLETE
-
WITHOUT MOTOR
1
PT065
N
S
MOTOR
1
PT066
P
UMPTEC #207 PUMP
–
AP52
PRESSURE REGULATOR
–
PT021
DESCRIPTION
1 REGULATOR BODY
2 SS SEAT & O-RING (PT020S)
3 PISTON AND SEAL (PT020A)
4 SPRING PLATE
5 SPRING
6 BRASS KNOB
7 REGULATOR COMPLETE (PT021)
7
2
1
6
5
4
3
