Nautilus MX3-500 - Solution Flow Path

23
Denotes Water
flow in high
pressure hose
Denotes
Chemical flow
Denotes by-pass
water flow from
pressure regulator
Denotes
incoming water
flow
MX3-500
Solution Flow Path
Solution Tank
Pump – AP52
Gauge
Filter
Pressure Regulator
PT021
Outlet Quick
Connect
Chemical Jug
Optional – Auto Fill Float
Valve Assembly
Optional Auto
Fill Inlet Quick
Connect
Optional
1750W Heater
