Nautilus MX3-500 - Parts List

52
KEY PART # DESCRIPTION KEY PART # DESCRIPTION
1 NM5704
RECOVERY TANK
21 AH101B
QUICK CONNECT FEMALE ¼”
2 NM5702
SOLUTION TANK
22 BR174
ADAPTER ¼” M
-
F
3 PFA11
WASHER 5/16” FLAT SS
23 NM5751
WASHER ½” FLAT SS
(BEHIND CONTROL PANEL)
4 NM5724
WHEEL 2
-
1/2” GRAY
23A NM5751A
WASHER ½” FLAT SS
WITH
NEOPRENE BACKING
5 NM5143
ACORN NUT CAP 5/16
-
18
24 NM5743
CONTROL PANEL PLATE
NS NM5137
SCREW 5/16
-
18 X 2.75” HX SS
25 NM5744A
MX
3
-
500 PANEL DECAL
6 NM5718
LID ASSY WASTE TANK
26 NM5009
CO
RD 12GA W/ PLUG (QTY 2)
7 PA187
SCREW
#10 X 5/8” PH SS
(QTY 6)
27 NM5038
CORD STRAIN RELIEF (QTY 2)
NS NM5718A
GASKET WASTE TANK DECK
27A NM5039
NUT CORD STRAIN RELIEF
8 NM5028
SCREW ¼
-
20 X1/2” SOCHD SS
28 PEA11
GATE VALVE 1
-
1/2” MPT
9 NM5066
WASHER
¼” FLAT SS
29 NM5759
CORD WRAP BRACKET (QTY 2)
10 NM5840
WAND HOLDER STRAP
LONG
TOP STRAP
30 NM5014
WASHER ¼” LOCK SS
11 NM5844
WAND HOLDER
BUCKLE
31 NM4063
SCREW ¼
-
20 X ¾” SOCHD SS
12 NM5842
WAND HOLDER STRAP SHORT
BOTTOM STRAP
32 NM5722
WHEEL 12”
with HUB CAP
13 BR319
ADAPTER ¾” MPT X ¾” MGH
NS NM5010
AXLE CAP
–
PUSH NUT
14 BR325
GARDEN HOSE CAP
33 NM4447
GREEN
NEON LIGHT 12
0V
14A BR600
GARDEN HOSE WASHER
34 NM5754
COOLING FAN
NS AH68
BARB 2” X 2” MPT PVC
35 NM5757
PLASTIC FAN COVER
15 AH224
FLASH CUFF 2” MALE
-
MPT
36 NM5753
SCREW
6
-
32 X ¾” PPH SS
(QTY 4)
NS AH201
FLASH CUFF 2” FEMALE 1.5”
37 NM5710A
BASE PLATE
ASSEMBLY
Comes with Lift Handle & Hinges
16 NM5714
ROCKER SWITCH DPST (QTY 4)
38 NA041
HANDLE
17 PT064
PRESSURE GAUGE 1000PSI
39 NM5700
BASE SKIRT
18 PT021
PRESSURE REGULATOR
500PSI
40 NM5750
HINGE (QTY 3)
19 NM5747
SCREW
8
-
32 X1” SOHD SS
(QTY 4)
41 NM5017
SCREW ¼
-
20 X ¾” HXHD SS
19A NM5793
NUT
8
-
32 NYLOCK SS
(QTY 4)
41A NM4261
NUT ¼
-
20 NYLOCK
20 NM5110
CIRCUIT BREAKER 10
AMP
42 NM5947
SCREW
10
-
24 x ½”PPH SS
(QTY 4)
