KEY PART # DESCRIPTION KEY PART # DESCRIPTION
42A
PHY094
-
034
NUT
10
-
24 NYLOCK SS
(QTY 4)
67 BR030
BARB ½” X 3/8” MPT
43 NM5748
AXLE REAR WHEELS
–
22.5”
68 NM5086
HOSE ½” ID CLEAR COIL
44 AP52
500PSI PUMP W
ITH MOTOR
69 PT065
205V
PUMP WITH
OUT
MOTOR
45 PT066
M58 1/2HP MOTOR ONLY
70 BR020
BARB 3/8” X ¼” MPT
46 AV14
VACUUM MOTOR 3
-
STAGE
71 BR272
ELBOW 45DEG ¼” STREET
47 NM5706
VACUUM MANIFOLD
NS BR282
ELBOW 90DEG ¼” STREET
47A PA010
VACUUM GASKET
72 NM5712
ADAPTER 2” FPT X SPG
48 NM5728
GATE VALVE 2” W/ KEEPER
73 NM5027
BRACKET SOL/REC TANK
49 NM5728A
GASKET VACUUM VALVE
74 NM5738
BRACKET TERMINAL BLOCKS
50 NM5141
SCREW
¼
-
20 X 3.25” SOCHD SS
(QTY 6)
75 NM5730
TERMINAL BLOCK 6 SPACE
51 NM5726
VACU
UM HOSE 2”
–
PER INCH
76 NM5732
TERMINAL BLOCK 10 SPACE
52 PA051
HOSE CLAMP 2
-
2.75”
77 NM5142
SCREW #6 X ½” PPH SS (QTY 6)
53 NM5705
DECAL VAC CONNECTION
78 NM5756
FAN GUARD
–
WIRE FORMED
54 NM5133
SCREW
¼
-
20 X 2.00” SOCHD SS
79 NM4031
NUT 6
-
32 NYL
OCK SS
55 NM5793
NUT
8
-
32 NYLOCK SS
80 NM5124
SCREW 8
-
32 X ½” PPH SS
56 NM5124
SCREW
8
-
32 X ½” PPH SS
(QTY 6)
81 NM5746
FILTER SS
-
¾” FPT
57 NM5752
LATCH
-
SLIDE
(QTY 2)
82 NM5098
BULKHEAD FITTING 3/8”
58 NM5120
SCREW
5/16
-
18 X 3/4
” H
X
H
D
SS
83 BR284
ELBOW 90DEG 3/8” STREET
59 PFA10
NUT
5/16
-
18 NYLOCK SS
84
PP14
-
806504
ACORN STRAINER ¾” FPT
60 NM5720
CASTER 5” (QTY 2)
85 NM5727
ADAPTER 2”MPT X H
PVC
61 NM5752B
LATCH HOOK
-
KEEPER
86 PA029
PIPE 2” ABS (13.5”)
62 NM5752A
SPACER
–
LATCH HOOK
87 NM5741E
CLAMP NYLON 2
-
2.5”
63 NM5128
SCREW 8
-
32 X ¾” PPH SS(QTY 4)
88
64 NM4261
NUT ¼
-
20 NYLOCK SS
89
65 BR132
NIPPLE 3/8” X ¼”
90 BR282
ELBOW 90DEG ¼” STREET
66 BR254
STREET TEE 3/8”
91 NM5742
BULKHEAD FITTING ¾” PVC
