KEY PART # DESCRIPTION KEY PART # DESCRIPTION
92 NM5744
NIPPLE ¾” X 2” PVC
NS NM5025
RIVET
–
VAC HOSE END
93 NM5093
HOSE ¾” ID CLEAR COIL
NS NM5713
ADAPTER 2”FPT X HSLIP ABS
94 PH09
HOSE CLAMP
NS NM5709
SPACER UNLOADER MOUNT
95 AP37
PUMP
-
OUT PUMP
NS NM5736
ISOLATOR
–
PUMP
MOUNT
96
PF20381
-
010
ELBOW 90 ¾” BARB QUAD FTTG
NS NM5794
SCREW 5/16
-
18 X 1” HXHD SS
97 NM5850
SCREW 10
-
24 X 1.25” PPH SS
NS NM5792
WASHER 5/16” FLAT FENDER
98 NM4255
WASHER #10 FLAT SS
NS NM5703H
WIRING HARNESS
-
UPPER
99 BR048P
BARB ¾” X ¾” MPT
NYLON
NS NM5701H
WIRING HARNESS
-
LOWER
100 NM5716
ROCKER SWITCH DUAL SPST
NS NM5705A
DECAL POWER PRIME VALVE
101 NM5735
FILTER CAP ASSEMBLY
NS NM5705B
DECAL DUAL CIRCUIT LIGHT
102 NM5741F
FLOAT VACUUM SHUTOFF
NS NM5711
DECAL NAUTILUS SIDE
(QTY 2)
103 NM4472
HOSE CLAMP W/THUMB SCREW
NS NM5758
KIT DUAL CIRCUIT WIRING
104 NM5715
SWITCH PANEL PLUG
NS NM4087
SCREW 1/4
-
20 x 5/8” SOC BH SS
105 BR049
BARB ¾” X ¾” FPT
NS NM5434
#6 INTERNAL STAR WASHER SS
CONTROL PANEL GROUND LUG
106
PHY106
-
028
RUBBER
VACUUM PLUG
NS
SERIAL NUMBER PLATE
WITH FOUR RIVETS
107 NM4263
SCREW TEK #10 X 5/8” SS
NS NM5933
3/16” INT STAR WASHER SS
FAN GROUND WIRE CONNECT
108 NM4460
CABLE
109 NM4462
SLEEVE #7 CABLE CLAMP
110 NM4116
GROMMET 3/8”
111 BR028
BARB
½” X ¼” MPT
112 PH07
HOSE CLAMP
113 NM5737
MOISTURE BARRIER
114 NM5433
1/4” INTERNAL STAR WASHER SS
115 NM5125
WASHER ½” FLAT ZINC PL
116 NM5725
GASKET VACUUM RISER PIPE
117 NM5705C
DECAL CSA WARNING
