NAVEE EasyRide 25 Pro - Page 8

11 12
EN EN
Product
Name NAVEE Electric Scooter
Model EasyRide 25 Pro-E EasyRide 25 Pro-D EasyRide 25 Pro-S
Dimensions
Vehicle: L × W × H (mm)
[1]
1110 × 463 × 1151
After Folding: L × W × H
(mm)
1110 × 461 × 531
Net Weight Vehicle Net Weight (kg) 15.9
Rider
Load Range (kg) 25–90
Age (years) 16–50
Body Length (cm) 120–200
Assembled
Electric Scooter
Max. Speed (km/h) 25 20 20
General Range (km)
[2]
Approx. 25
Max. Climbing Angle (%) Approx. 14
Suitable Surfaces
Cement or asphalt road, with benches of less than 1 cm or crevices
narrower than 3 cm
Operating Temperature (°C) -10 to 40
Storage Temperature (°C) -20 to 45
IP Rating IPX5
Charging Time (h) Approx. 8
Battery Pack
Model T2417-B64A
Nominal Voltage (VDC) 21.6
Max. Charge Voltage (VDC) 25.2
Rated Energy (Wh) 220.32
Intelligent Battery
Management System
Over-heating, short circuit, over-current, over-discharge, and
over-charge protection
Normal Charging
Temperature Range (°C)
0 to 40
Rated Capacity (Ah) 10.2
Wheel Motor Rated Power (kW; W) 0.3; 300 0.3; 300 0.25; 250
Battery Charger
Model
[3]
FY0422521500E
Output Power (kW; W) 0.0378;37.8
Input 100-240 V~ 50/60 Hz
Rated Output (VDC; A) 25.2; 1.5
Tire Front & Back Tires Maintenance-free Inner Hollow Tires
Bluetooth
Frequency Band (s) 2.4000–2.4835 GHz
Max. RF Power (dBm) 8
[1] Vehicle height: From the ground to the top of the scooter.
[2] General range: Measured when there is no wind and at 25°C, the scooter is fully charged to ride at a constant speed of 15 km/h on a flat
surface with a load of 75 kg.
[3] To recharge the battery, only use the battery charger provided in the package. Please see battery charger parameters in Specifications.
4. Specifications
5. Certification
Restriction of Hazardous Substances Directive (RoHS)
This SPACEWALKER PTE. LTD. product, with included parts (cables, cords, and so on) meets the restriction of the use
of certain hazardous substances in electrical and electronic equipment 2011/65/EU Annex II and its amendment
Directive (EU) 2015/863.
This device meets the EU requirements on the limitation of exposure of the general public to
electromagnetic fields by way of health protection.
Hereby, SPACEWALKER PTE. LTD. declares that the radio equipment type: [EasyRide 25 Pro-E],
[EasyRide 25 Pro-D] and [EasyRide 25 Pro-S] are in compliance with Directive 2014/53/EU and 2006/42/
EC. The full text of the EU declaration of conformity is available at the following internet address:
www.naveetech.com
EU Declaration of Conformity
European Union Compliance Statement
Battery recycling information for the European Union
Batteries or packaging for batteries are labeled in accordance with European Directive 2006/66/EC and
amendment 2013/56/EU concerning batteries and accumulators and waste batteries and accumulators.
The Directive determines the framework for the return and recycling of used batteries and accumulators
as applicable throughout the European Union. This label is applied to various batteries to indicate that
the battery is not to be thrown away, but rather reclaimed upon end of life per this Directive.
In accordance with the European Directive 2006/66/EC and amendment 2013/56/EU, batteries and
accumulators are labeled to indicate that they are to be collected separately and recycled at end of life.
The label on the battery may also include a chemical symbol for the metal concerned in the battery (Pb
for lead, Hg for mercury, and Cd for cadmium). Users of batteries and accumulators must not dispose of
batteries and accumulators as unsorted municipal waste, but use the collection framework available to
customers for the return, recycling, and treatment of batteries and accumulators. Customer participation
is important to minimize any potential eects of batteries and accumulators on the environment and
human health due to the potential presence of hazardous substances.
Before placing electrical and electronic equipment (EEE) in the waste collection stream or in waste
collection facilities, the end user of equipment containing batteries and/or accumulators must remove
those batteries and accumulators for separate collection.
All products bearing this symbol are waste electrical and electronic equipment (WEEE as in directive
2012/19/EU) which should not be mixed with unsorted household waste. Instead, you should protect
human health and the environment by handing over your waste equipment to a designated collection
point for the recycling of waste electrical and electronic equipment, appointed by the government or
local authorities. Correct disposal and recycling will help prevent potential negative consequences to
the environment and human health. Please contact the installer or local authorities for more information
about the location as well as terms and conditions of such collection points.
Waste Electrical and Electronic Equipment (WEEE) Directive
