NAVEE N65 - Specifications

16
EN
Product
Name NAVEE Electric Scooter N65
Model N65
Dimensions
Vehicle: L × W × H (mm)
[1]
1190 × 510 × 1220
After Folding: L × W × H (mm) 1210× 205 × 406
Net Weight Vehicle Net Weight (kg) 23.5
Rider
Load Range (kg) 25-120
Age (years) 16-50
Body Length (cm) 120-200
Assembled Electric
Scooter
Max. Speed (km/h) 25
General Range (km)
[2]
Approx. 65
Max. Climbing Angle (%) Approx. 25
Suitable Surfaces
Cement or asphalt road, with benches of less than 1 cm or crevices
narrower than 3 cm
Operating Temperature (° C) -10 to 55
Storage Temperature (° C) 0 to 45
IP Rating IPX4
Charging Time (h) Approx. 7-8
Battery Pack
Model FS004-01
Nominal Voltage (VDC) 48
Max. Charge Voltage (VDC) 54.6
Rated Energy (Wh) 600
Intelligent Battery
Management System
Over-heating, short circuit, over-current, over-discharge, and over-
charge protection
Normal Charging
Temperature Range (° C)
0 to 45
Rated Capacity (Ah) 12.5
Wheel Motor Rated Power (kW; W) 0.5; 500
Battery Charger
Output Power (kW; W) 0.1092; 109.2
Input Voltage (VAC) 100–240
Rated Output (VDC; A) 54.6; 2.0
Model
[3]
FY1505462000
Tire Front & Back Tires 10-inch pneumatic tire
Bluetooth
Frequency Band (s) 2.4000–2.4835 GHz
Max. RF Power (dBm) 8
11. Specications
[1] Vehicle height: From the ground to the top of the scooter.
[2] General range: Measured when there is no wind and at 25° C, the scooter is fully charged to ride at a constant speed of 15 km/h on a at
surface with a load of 75 kg.
[3] To recharge the battery, only use the battery charger provided in the package. Please see battery charger parameters in Specications.
