Wheels, brake pads and other vulnerable parts are worn or damaged and need to be replaced, please contact the
after-sales service in time.
Item
Service
Object
Actions
Every
month
Every 3
months
Every
500 km/
6 months
Every
1000 km/
1 year
Every
10000 km/
3 years
Functions
Brake
Adjustment
Adjust the Disc Brake
Before adjusting, get yourself a 4 mm
wrench (prepared by the user) and
make sure the scooter is turned o and
not being charged.
During adjusting, pull the end of the
brake cable to make the cable tight.
If the brake is too tight, use the tool
to loosen the screw by turning it
counterclockwise, pull the disc brake
rocker arm outwards, and then tighten
the screw. If the brake is too loose, use
the tool to loosen the screw by turning
it counterclockwise, push the disc brake
rocker arm forwards, and then tighten
the screw.
√ √ √
Adjust the Mechanical Brake
Before adjusting, get yourself a 5 mm
wrench (prepared by the user) and
make sure the scooter is turned o and
not being charged.
When the brake is too tight, use the
tool to turn the nut on the
screw rod counterclockwise, so
as to slightly shorten the brake
cable's exposed bottom part.
When the brake is too loose, use
the tool to turn the nut on the
screw rod clockwise, so as to
slightly lengthen the brake cable's
exposed bottom part.
√ √ √
Charging
Charge the scooter at a suitable
temperature. The indicator on the
battery charger is red when the scooter
is charging, and turns green when the
scooter is fully charged. The control
panel will show the charging status
simultaneously during charging.
√ √ √
Steering
Turn the handlebar 60° to the left and
right to make sure the turning angle
is correct and the steering is free from
resistance and stagnation.
√ √
Important
Components
Battery
Assembly
Fully charge the scooter before leaving
it unused for a long time, and turn it on
to charge every 60 days.
√
4. Specifications
Product
Name NAVEE Electric Scooter
Model N65i-E N65i-D
Dimensions
Vehicle: L × W × H (mm)
[1]
1200 × 610 ×1250
After Folding: L × W × H (mm)
1230 × 205 × 580
Net Weight Vehicle Net Weight (kg) 22.8
Rider
Load Range (kg) 25–120
Age (years) 16–50
Body Length (cm) 120–200
Assembled
Electric Scooter
Max. Speed (km/h) 25 20
General Range (km)
[2]
Approx. 65
Max. Climbing Angle (%) Approx. 24
Suitable Surfaces
Cement or asphalt road, with benches of less than 1 cm or crevices narrower
than 3 cm
Operating Temperature (°C) -10 to 40
Storage Temperature (°C) -20 to 45
IP Rating IPX5
Charging Time (h) Approx. 10
Battery Pack
Model T2213–BD5B
Nominal Voltage (VDC) 46.8
Max. Charge Voltage (VDC) 54.6
Rated Energy (Wh) 585
Intelligent Battery
Management System
Over-heating, short circuit, over-current, over-discharge, and over-charge
protection
Normal Charging Temperature
Range (°C)
0 to 40
Rated Capacity (Ah) 12.5
Wheel Motor Rated Power (kW; W)
0
.
45; 450
Battery Charger
Model
[3]
NBW54D601D3D
Output Power (kW; W) 0.07; 70
Input 100-240 V ~ 50/60 Hz
Max. Output Voltage (VDC) 54.6
Rated Output (VDC; A) 53.6; 1.3
Tire Front & Back Tires 10.5-inch Tubeless Tires
Bluetooth
Frequency Band (s) 2.4000–2.4835 GHz
Max. RF Power (dBm) 8
[1] Vehicle height: From the ground to the top of the scooter.
[2] General range: Measured when there is no wind and at 25°C, the scooter is fully charged to ride at a constant speed of 15 km/h on a flat
surface with a load of 75 kg.
[3] To recharge the battery, only use the battery charger provided in the package. Please see battery charger parameters in Specifications.
