Navien KDB-535GTD User Manual

Medium-sized gas boiler
59
4) Iron boiler
Model
Classification
2035GPD 2035GPS 2035GPG
HeatingOutput
kcal/h
(kW)
200,000
(232.5)
200,000
(232.5)
-
Hot waterOutput
kcal/h
(kW)
130,000
(151.1)
-
200,000
(232.5)
Hot water supply
capacity ( △ 40 ℃ )
ℓ /min
63 - 83
Purpose Combi Heating only Hot water only
LNG
%
92.0 92.0 92.0
Effici
ency
(Total)
LPG
%
92.0 92.0 92.0
City gas (13A), LP Gas
Maximum allowable
working pressure
kgf/cm
2
(MPa)
3.5 (0.343)
Heat transfer area
m
2
6.46
Heating area
m
2
1323 1323 -
Volume of pipe water
ℓ
237 255 255
Weight
kg
475 450 450
Power supply 1 φ , 220V, 50Hz
Burner Model no. KPG-200A
Power consumption
W
366
Gas pressure
mmH
2
O
LP gas: 280 ± 50, LNG : 200
＋50
－100
Fuel consumption LNG : 24Nm
3
/h, 252,000kcal/h(293.0kW), LPG : 21kg/h
Width
mm
796
Depth ＋
Burner
mm
1,165
Product
size
Height
mm
1,716
Hot water
inlet · outlet
A
80 80 －
Drain
A
80 80 80
Discharge
outlet
A
80 80 80
Hot water
inlet · outlet
A
20 － 80
Piping
size
Gas inlet
A
32
Flue size
φ
200
Exhaust gas
℃
250 or less
