Maximum Liquefied Propane Delivery Capacity
In Thousands of BTU / H (0.5” WC Pressure Drop)
Pipe Size
Length (including fittings)
10 ft.
(3 m)
20 ft.
(6 m)
30 ft.
(9 m)
40 ft.
(12 m)
50 ft.
(15 m)
60 ft.
(18 m)
70ft.
(21m)
80ft.
(24m)
90ft.
(27m)
100ft.
(30m)
125ft.
(38m)
200 ft.
(60 m)
250 ft.
(76 m)
1
/
2
in 291 200 160 137 122 110 101 94 89 84 74 67 62
3
/
4
in 608 418 336 287 255 231 212 197 185 175 155 140 129
1 in 1,150 787 632 541 480 434 400 372 349 330 292 265 243
1
1
/
4
in 2,350 1,620 1,300 1,110 985 892 821 763 716 677 600 543 500
1
1
/
2
in 3,520 2,420 1,940 1,660 1,480 1,340 1,230 1,140 1,070 1,010 899 814 749
2 in 6,790 4,660 3,750 3,210 2,840 2,570 2,370 2,200 2,070 1,950 1,730 1,570 1,440
The inlet gas pressure must be maintained between 3.5 in and 10.5 in WC for natural gas and between 8.0 in and 13.5 in WC for liquefied
propane.
The appliance and its individual shutoff valve must be disconnected from the gas supply piping system during any pressure testing of that
system at test pressures in excess of
1
/
2
psi (3.5 kPa).
The appliance must be isolated from the gas supply piping system by closing its individual manual shutoff valve during any pressure testing of
the gas supply piping system at test pressures equal to or less than
1
/
2
psi (3.5 kPa).
NOTE
●
For installations using CSST (flexible) gas piping, please refer to the sizing charts provided by the manufacturer.
●
The use of single-stage regulators are recommended. Dual-stage regulators could cause operational issues with the boiler.
