DIAGNOSTICMANUAL
Step
ActionDecision
9CVerifyaftertreatmentsystemisfreeofrestrictions.Using
EST,usetheplaybackfeatureandgraphthefollowing
signalvaluesfromLugDownT est:
SignalValues:
•EngineSpeed
•Turbocharger1TurbineOutletPressure(TC1TOP)
ComparesnapshottoGraph4andassociatedGraph
Analysispage126.
IsTC1TOPsignaloperatingasperGraph4Graph
Analysis?
Yes:Gotostep9D
No:RepairTC1TOPissue(See
ElectronicControlSystemsDiagnostics
inEngineDiagnosticManual).After
repairsarecomplete,retestfororiginal
problem.
Step
ActionDecision
9D
CheckforanIntakeManifoldPressure(IMP)issue.Use
theplaybackfeatureinServiceMaxx™,andgraphthe
followingsignalvaluesfromLugDownT est:
SignalValues:
•EngineSpeed
•IntakeManifoldPressure(IMP)
•AcceleratorPedalPosition1(APP1)
•VehicleSpeed
ComparesnapshottoGraph5andassociatedGraph
Analysispage127.
IsIMPoperatingasperGraph5GraphAnalysis?
Yes:Gotostep10
No:DiagnoseandrepairIMPissue
(SeePerformanceDiagnosticssectionin
EngineDiagnosticManual).Afterrepairs
arecomplete,retestfororiginalproblem.
108
