Navistar MaxxForce 15 - 9.4. SYMPTOM 3 (HEAVY DUTY): SPN 3719 ACTIVE ONLY OR FREQUENT REGENS (MORE THAN ONE PARKED REGEN PER DAY)

DIAGNOSTICMANUAL
Step
ActionDecision
3
DetermineifPDOCorDOCiscontaminated.Removethe
PDOCandDOC(seeExhaustSystemServiceManual),and
checkforsignsoflubeoilandcoolantcontamination.
NOTE–Ablackstainingintheexhausttailpipecanoccur
onapplicationsthatexperiencehighidletimes.Thisis
normalandtheDPFshouldNOTbereplaced.
ArethePDOCandDOCcontaminated?
Yes:RemoveDPF ,andthengoto
step4.
No:gotostep5
Step
ActionDecision
4
DetermineifDPF,DOC,andPDOCarereusableseeDPF
andDOCreuseguidelinespage159.
BasedonDPFandDOCRe-UseGuidelines,aretheDPF ,
DOC,andPDOCreusable?
Yes:Gotostep6
No:Replacefailedcomponent(s).
Afterrepairsarecomplete,gotostep
6.
Step
ActionDecision
5
Determineifremovedaftertreatmentsystemcomponents
needtobecleanedseeDPFandDOCreuseguidelinespage
159.
BasedonDPFandDOCRe-UseGuidelines,doanyofthe
removedaftertreatmentsystemcomponentsneedtobe
cleaned?
Yes:Cleancomponentsusing
appropriatecleaningequipment.After
cleaningprocedureiscomplete,install
componentsandgotostep7.
No:Installremovedaftertreatment
systemcomponents,andgotostep7.
Step
ActionDecision
6
Determinerootcauseofexhaustsystemcontamination.(See
EngineSymptomsDiagnosticssectioninEngineDiagnostic
Manual.)
Afterrepairsarecomplete,gotostep
7.
92
