NAWA TR26 User Manual

Version 13 – 01/2019 5
3 Setup and functions
3.1 Overview
Fig. 1
1 Probe
2 Bayonet lock (see chapter 3.2)
3 Measuring device
3.2 Bayonet lock
Fig. 2a Fig. 2b
Probe and measuring device as well as measuring device and charging station are
connected via bayonet lock. To do this, insert both parts into the matching opening
(see red arrow) and turn until both parts are locked into place.
3.3 Display window
Fig. 3
1 Touch sensor
2 pH value display
3 Temperature display (in °C)
4 Battery level display
1
2
3
2
1
4
3
