NDS TEMPRA TBL 100 User Manual

4. STRUCTURE
The battery has 2 terminals (negative and positive)
with threaded hole and 1 Multicolour LED indicator
on top.
On the side, there's a "Setup and connections"
compartment to make the settings for battery
operation, to connect it to the N-BUS network and to
connect the DTB01 touch screen display (optional).
See the following 2 figures for all references.
6
TERMINALS AND LED INDICATOR
REFERENCE
FUNCTION
A
Negative terminal
B
Positive terminal
C
Multicolor LED indicator
D
Connection compartment
D
C
A
B
Fig.1
