You can install automotive poles with an M8 screw, or

use a bolt in case you want to use eyelet connectors.

CONNECTION COMPARTMENT

REFERENCE

FUNCTION

Green connector (not used)

Red connector (not used)

ON/OFF Button

N-BUS_1 connection for Display

or other N_BUS device

N-BUS_2 connection for Display

or other N_BUS device

6 channels Dip switch selector

Fig.2
