10
1.
DT330/DT730
Example: DTL-8LD-1/ITL-8LD-1
(1) Security Button (DT730 only)
The user can prevent information leakage from
terminal by simple operation.
(2) Call Indicator Lamp
Lamp at top corner of DT Series Display flashes
when a call terminates to the terminal. Lamp lights
steadily when a message has been left.
(3) LCD
LCD (Liquid Crystal Display) provides DT Series
activity information plus data, time and Soft Key
Operation.
(4) Exit
The user can exit from the Help key mode by
pressing this key.
(5) Soft Keys
Any feature shown at the bottom of the LCD is
available. The appropriate feature key is displayed
on the screen according to the call handling pro-
cess.
(6) Help
Explanations of the Soft Keys can be called up on
the LCD by pressing this key.
1
2
ABC
3
DEF
4
GHI
5
JKL
6
MNO
7
PQRS
8
TUV
9
WXYZ
0
#
Menu
HOLD
Transfer
Speaker
Recall
Feautre
Answer
Mic
(1)
(3)
(4)
(6)
(5)
(7)
(8)
(9)
(10)
(11)
(12)
(13)
(14)
(19) (18) (17)
(2)
Scroll
Exit Help
Redial
(16)
(15)
