English-7
English
Parts Name and Functions
Control Panel
1
2
3
4
5
6
7
1 MENU button (MENU)
Turns on/off the OSD menu.
2 SOURCE button (SOURCE)
Acts as INPUT button within OSD menu.
(Toggle switches between [HDMI1], [HDMI2], [HDMI3], [VGA],
[USB]). These are available input only, shown as their factory
preset name.
3 PLUS button (+)
Acts as RIGHT button to increase the adjustment with OSD
menu.
Increases the audio output level when the OSD menu
is turned off.
4 MINUS button (-)
Acts as LEFT button to decrease the adjustment with OSD
menu.
Decreases the audio output level when the OSD menu
is turned off.
5 UP button ( )
Acts as UP button to move the highlighted area up to select
adjustment items within OSD menu.
6 DOWN button ( )
Acts as DOWN button to move the highlighted area down to
select adjustment items within OSD menu.
G POWER button ( )
Switches the power on/off. See also page 15.
To Next Page
