Installation for using the Stand Base
IMPORTANT: Do not apply pressure to the screen display area which may
compromise the integrity of the display. The manufacturer’s warranty does not
cover user abuse or improper installations.
Attaching the Stand Base
E657Q
Stand Screw x 4
M6 (25mm)
E557Q / E507Q / E437Q / E327
Stand Screw x 4
M4 (20mm)
1. Place the display face down on a soft and at surface to prevent
scratching and damage.
2. Carefully align the stand base to the button of the display and fasten the
screws with a cross-head screwdriver.
CAUTION:
The stand base is very heavy. Install with care to avoid injury such as dropping the
stand base onto one's foot.
