VOLUME DISPLAY ICONS
Table 4: Volume Display Icons
Feature Icon Description
Handset Ringing
Volume
Shows the ringing volume of the handset for incoming calls.
Soft Ring Volume
Shows the soft ring volume of the handset for incoming calls.
Headset Call Volume
Shows the volume level of the headset during a call.
Handset Call Volume
Shows the volume level of the handset during a call.
Speaker Call Volume
Shows the volume level of the speaker during a call.
MONITOR PRESENCE ICONS
Table 5: Monitor Presence Icons for ITY-6D phones
Type Status
Programmable key
LED
Icon
Personal Directory
Subscription failed
LED is not lit
Online
LED is not lit
Ringing (Incoming)
LED is not lit
Ringing (Outgoing)
LED is not lit
Active call
LED is not lit
BLF
Idle
LED is not lit
None
Ringing
Blinking Green
None
On the Phone
(The Phone is in use)
Red
None
