❷ Specifications
Thissectionprovidestechnicalinformationaboutprojector’sperformance.
[M403W/M363W/M323W/M403X/M363X/M323X/M283X]
Optical
Model Number NP-M403W NP-M363W NP-M323W NP-M403X NP-M363X NP-M323X NP-M283X
Projection
System
Single DLP® chip (0.65", aspect 16:10) Single DLP® chip (0.55", aspect 4:3)
Resolution*
1
1280 × 800 pixels (WXGA) 1024 × 768 pixels (XGA)
Lens Manual zoom and focus
Zoom Ratio = 1.7
F2.4–3.1/f = 17.09–29.05 mm
Lamp 270 W AC
(219 W in NOR-
MAL)
(162 W in ECO)
250 W AC
(189 W in NOR-
MAL)
(150 W in ECO)
225W AC
(171W in NOR-
MAL)
(135W in ECO)
270 W AC
(219 W in NOR-
MAL)
(162 W in ECO)
250 W AC
(189 W in NOR-
MAL)
(150 W in ECO)
225W AC
(171W in NOR-
MAL)
(135W in ECO)
200W AC
(160W in NOR-
MAL)
(120W in ECO)
Light Output*
2
*
3
4000 lumens 3600 lumens 3200 lumens 4000 lumens 3600 lumens 3200 lumens 2800 lumens
NORMAL: 81% NORMAL: 76% NORMAL: 81% NORMAL: 76%
ECO: 60%*
4
Contrast Ratio*
3
(full white: full
black)
10000:1 with DYNAMIC CONTRAST ON
Image Size
(Diagonal)
30–300 inches/0.76 m–7.6 m (16:10) 30–300 inches/0.76 m–7.6 m (4:3)
Projection
Distance
(Min.–Max.)
29"–312" (wide) / 50"–531" (tele)
0.75–7.94 m (wide) / 1.28–13.5 m (tele)
35"–369" (wide) / 60"–627" (tele)
0.89–9.37 m (wide) / 1.52–15.93 m (tele)
Projection Angle 10.5° (wide)/17.5°–17.6° (tele) 10.5° (wide)/17.5°–17.6° (tele)
*1 Effectivepixelsaremorethan99.99%.
*2 Thisisthelightoutputvalue(lumens)whenthe[PRESET]modeissetto[HIGH-BRIGHT].Ifanyothermodeisselectedasthe
[PRESET]mode,thelightoutputvaluemaydropslightly.
*3 CompliancewithISO21118-2012
*4ThemaximumpowerbecomesequivalenttopowerinECO(ECOMODE).
Electrical
Model Number NP-M403W NP-M363W NP-M323W NP-M403X NP-M363X NP-M323X NP-M283X
Inputs 1 × RGB/Component (D-Sub 15 P), 2 × HDMI Type A (19P, HDMI
®
Terminal) HDCP supported*
5
,
1 × Video (RCA), 1 × (L/R) RCA Audio, 1 × Stereo Mini Audio
Outputs 1 × RGB (D-Sub 15P), 1 × Stereo Mini Audio
PC Control 1 × PC Control Port (D-Sub 9P)
Wired LAN Port 1 × RJ-45 (10BASE-T/100BASE-TX)
Wireless LAN
Port (Optional)
IEEE 802.11 b/g/n (optional USB Wireless LAN Unit required)
USB Port 1 × Type A, 1 × Type B
MIC Input 1 × Monaural Mini Audio
Color Reproduc-
tion
10-bit signal processing (1.07 billion colors) (USB-A, LAN: 16.7 million colors)
*5 HDMI
®
(DeepColor,LipSync,3D)withHDCP
 WhatisHDCP/HDCPtechnology?
 HDCPisanacronymforHigh-bandwidthDigitalContentProtection.HighbandwidthDigitalContentProtection(HDCP)isasystem
forpreventingillegalcopyingofvideodatasentoveraHigh-DenitionMultimediaInterface(HDMI).
 IfyouareunabletoviewmaterialviatheHDMIinput,thisdoesnotnecessarilymeantheprojectorisnotfunctioningproperly.With
theimplementationofHDCP,theremaybecasesinwhichcertaincontentisprotectedwithHDCPandmightnotbedisplayed
duetothedecision/intentionoftheHDCPcommunity(DigitalContentProtection,LLC).
 Video:DeepColor;8/10/12-bit,LipSync
 Audio:LPCM;upto2ch,samplerate32/44.1/48KHz,samplebit;16/20/24-bit
*6 Animagewithhigherorlowerresolutionthantheprojector’snativeresolution(M403X/M363X/M323X/M283X:1024×768/
M403W/M363W/M323W:1280×800)willbedisplayedwithAdvancedAccuBlend.

NEC M323W Specifications

General

Native aspect ratio	16:10
Projection distance	0.76 - 13.53 m
Vertical scan range	50 - 120 Hz
Horizontal scan range	15 - 100 kHz
Projection technology	DLP
Supported aspect ratios	16:10, 16:9
Contrast ratio (typical)	10000:1
Screen size compatibility	30 - 300 \
Projector native resolution	WXGA (1280x800)
Keystone correction, vertical	-30 - 30 °
Keystone correction, horizontal	-25 - 25 °
Focus	Manual
Throw ratio	1.2 - 2.04:1
Zoom capability	Yes
Focal length range	17.09 - 29.05 mm
Aperture range (F-F)	2.4 - 3.1
Lamp power	225 W
Lamps quantity	1 lamp(s)
Light source type	Lamp
Lamp power (economic mode)	135 W
Service life of light source	5500 h
Service life of light source (economic mode)	8000 h
Analog signal format system	NTSC, NTSC 4.43, PAL, PAL 60, PAL M, SECAM
Supported graphics resolutions	640 x 480 (VGA), 720 x 480, 720 x 576, 800 x 600 (SVGA), 832 x 624, 1024 x 768 (XGA), 1152 x 864 (XGA+), 1152 x 870, 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1360 x 768 (WXGA), 1376 x 768, 1440 x 1050, 1440 x 900, 1600 x 1200 (UXGA), 1600 x 900, 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080)
DVI port	No
Audio (L/R) in	1
USB connector type	USB Type-A, USB Type-B
HDMI connector type	Full-size
Serial interface type	RS-232
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Maximum digital resolution	1920 x 1080 pixels
Noise level	30 dB
Certification	CE; EAC; Gost-R; TÜV GS
RMS rated power	20 W
Placement	Desktop
Product type	Standard throw projector
Product color	White
Market positioning	Portable
Cable lock slot type	Kensington
Power source	AC
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	286 W
Power consumption (standby)	0.4 W
Power consumption (typical)	224 W
Power consumption (economy mode)	202 W
Power consumption (network standby)	2.9 W
Storage temperature (T-T)	-10 - 50 °C
Operating temperature (T-T)	5 - 40 °C
Operating relative humidity (H-H)	20 - 80 %
Sustainability certificates	RoHS
Cables included	AC, VGA
Remote control type	IR

Weight and Dimensions

Depth	285.9 mm
Width	367.9 mm
Height	97.5 mm
Weight	3480 g
