NEC M323W - Attaching the Optional Cable Cover (NP05 CV)

147
8. Appendix
Attaching the Optional Cable Cover (NP05CV)
Anoptionalcablecover(NP05CV)isavailableforhidingcables.
CAUTION:
• Besuretotightenthescrewsafterattachingthecablecover.Failuretodosomaycausethecablecovertocome
offandfall,resultingininjuryordamagetothecablecover.
• Donotputbundledcablesinthecablecover.Failuretodosomaydamagethepowercord,resultingare.
• Donotforceexcessivepressuretothecablecover.Doingsomaycausedamagetothecablecover,resulting
ininjury.
Attaching the cable cover
Attachthecablecoverafterinstallingtheprojectorontheceilingandconnectingcables.
Toolneededforattaching:
• Phillipsscrewdriver(plus-head)
1. Aligntwotabsontheoutsideofthecablecoverwithgroovesoftheprojectorandpushthetopend.
• Atthesametimetwotabsontheinsideofthecablecoverwillbeengagedintherespondinggroovesofthe
projector.
NOTE:
• Becarefulnottogetcablescaughtinbetweenthecablecoverandtheprojector.
2. Tightenthecablecoverscrews.
• Besuretotightenthescrews.
1
1
2
2
Removing the cable cover
1. LoosenthecablecoverscrewsuntilthePhillipsscrewdrivergoesintoafreewheelingcondition
1
1
2. Removethecablecover.
Push up the cable cover slightly and rotate it to release.
