24
2. Projecting an Image (Basic Operation)
[M403W/M363W/M323W/M403X/M363X/M323X/M283X/M403H/M323H]
1. Press the ▼ ( ) button on the projector cabinet
withnomenusdisplayed.
The Keystone screen will be displayed on the screen.
• PresstheKEYSTONEbuttonwhenusingtheremote
control.
2. Press the ▼buttontoselect[VERTICAL]andthen
use the ◀ or ▶sothattheleftandrightsidesofthe
projectedimageareparallel.
* Adjusttheverticalkeystonedistortion.
Projected area
Screen frame
3. Aligntheleft(orright)sideofthescreenwiththe
left(orright)sideoftheprojectedimage.
• Usetheshortersideoftheprojectedimageasthe
base.
• Intherightexample,usetheleftsideasthebase.
Align left side
4. Press the ▲buttontoselect[HORIZONTAL]andthen
use the ◀ or ▶sothatthetopandbottomsidesof
theprojectedimageareparallel.
• Adjustthehorizontalkeystonedistortion.
5. Repeat steps 2 and 4 to correct keystone distor-
tion.
