1. Introduction
Terminal Panel Features
1. COMPUTERIN/ComponentInputTerminal(Mini
D-Sub15Pin)
(→page90,92,94)
2. COMPUTERAUDIOINMiniJack(StereoMini)
(→page90,91,93)
3. HDMI1INTerminal(TypeA)
(→page90,91,95)
4. HDMI2INTerminal(TypeA)
(→page90,91,95)
5. USB(PC)Port(TypeB)
(→page90)
6. MONITOROUT(COMPUTER)Terminal(MiniD-
Sub15Pin)
(→page92)
7. AUDIOOUTMiniJack(StereoMini)
(→page92)
8. VIDEOINTerminal(RCA)
(→page93)
9. VIDEOAUDIOINL/MONO,R(RCA)
(→page93)
10.LANPort(RJ-45)
(→page96)
11.USBPort(TypeA)
For USB memory or optional Wireless LAN unit
(→
page97)
12.PCCONTROLPort(D-Sub9Pin)
(→page116)
 Use this port to connect a PC or control system.
Thisenablesyoutocontroltheprojectorusingserial
communicationprotocol.Ifyouarewritingyourown
program,typicalPCcontrolcodesareonpage116.
13511 4 78
6212
10
9
