6. Installation and Connections
[ME401X/ME361X/ME331X/ME301X]
Thefurtheryourprojectorisfromthescreenorwall,thelargertheimage.Theminimumsizetheimagecanbeisap-
proximately25"(0.64m)measureddiagonallywhentheprojectorisroughly35inches(0.9m)fromthewallorscreen.
Thelargesttheimagecanbeis300"(7.6m)whentheprojectorisabout435inches(11.0m)fromthewallorscreen.
300"
240"
200"
180"
150"
120"
100"
80"
11.0/435
"
8.8/348
"
6.6/260
"
5.5/216
"
4.4/173
"
3.6/144
"
2.9/115
"
2.2/86
"
1.4/57
"
40"
7.3/289
"
60"
30"
25"
1.1/
42
"
0.9/
35
"
Distance (Unit: m/inch)
Lens center
Screen Size
Screen Size (Unit: cm/inch)
609�6(W) × 457�2(H) / 240(W) × 180(H)
487�7(W) × 365�8(H) / 192(W) × 144(H)
406�4(W) × 304�8(H) / 160(W) × 120(H)
365�8(W) × 274�3(H) / 144(W) × 108(H)
304�8(W) × 228�6(H) / 120(W) × 90(H)
243�8(W) × 182�9(H) / 96(W) × 72(H)
203�2(W) × 152�4(H) / 80(W) × 60(H)
162�6(W) × 121�9(H) / 64(W) × 48(H)
121�9(W) × 91�4(H) / 48(W) × 36(H)
81�3(W) × 61�0(H) / 32(W) × 24(H)
61�0(W) × 45�7(H) / 24(W) × 18(H)
50�8(W) × 38�1(H) / 20(W) × 15(H)
TIP:
• Thedistancesareindicatedbyintermediatevaluesbetweenteleandwide.Useasaruleofthumb.
• Formoredetailsonthrowdistance,seepage88.
