9. Maintenance
2. Remove the lamp housing.
(1) Loosen the three screws securing the lamp housing until the phillips screwdriver goes into a freewheeling
condition.
• The three screws are not removable.
• One of the screws is interlocked to prevent electric shock. Do not attempt to circumvent this interlock.
(2) Remove the lamp housing by holding it.
CAUTION:
Make sure that the lamp housing is cool enough before removing it.
Interlock
To replace the lamp:
1. Remove the lamp cover.
(1) Loosen the lamp cover screw.
• The lamp cover screw is not removable.
(2) Push and slide the lamp cover off.
To Next Page
