Specifications
Monitor Specifications MultiSync E242N Monitor Notes
LCD Module Diagonal:
Viewable Image Size:
Native Resolution (Pixel Count):
60.47 cm/23.8 inches
60.47 cm/23.8 inches
1920 x 1080
Active matrix; thin film transistor (TFT) liquid crystal
display (LCD); 0.275 mm dot pitch; 250 cd/m
2
white
luminance; 1000:1 contrast ratio (typical), (5000:1
Contrast ratio, DV MODE ON).
Input Signal
DisplayPort: DisplayPort Connector: Digital RGB DisplayPort V1.1a (HDCP 1.3)
VGA: Mini D-Sub 15-pin: Analog RGB
Sync
0.7 Vp-p/75 ohm
Separate sync.TTL level Positive/Negative
HDMI: HDMI Connector: Digital YUV
Digital RGB
HDMI (HDCP 1.4)
Display Colors 16,777,216 Depends on display card used.
Synchronization Range Horizontal:
Vertical:
31.5 kHz to 83.0 kHz
56 Hz to 75 Hz
Automatically
Automatically
Response Time 6 ms (Gray to gray Typ.)
Viewing Angle Left/Right:
Up/Down:
±89° (CR > 10)
±89° (CR > 10)
Active Display Area Landscape: Horiz.:
Vert.:
Portrait: Horiz.:
Vert.:
527.04 mm/20.7 inches
296.46 mm/11.7 inches
296.46 mm/11.7 inches
527.04 mm/20.7 inches
USB Hub I/F:
Port:
Load Current:
SuperSpeed USB (USB 3.1 Gen 1)
Upstream 1
Downstream 3
5 V/0.9 A (Max.)
Upstream port applicable to USB monitor control.
AUDIO
AUDIO Input: STEREO Mini Jack:
DisplayPort Connector:
HDMI Connector:
Analog Audio
Digital Audio
Digital Audio
Stereo L/R 0.5 Vrms 20 Kohm
PCM 2ch 32, 44.1, 48 kHz (16/20/24bit)
PCM 2ch 32, 44.1, 48 kHz (16/20/24bit)
Headphone Output: STEREO Mini Jack: Headphone Impedance 32 Ohm
Speakers Practical Audio Output: 1.0 W + 1.0 W
Power Supply 100 - 240 V, 50/60 Hz
Current Rating 0.80 - 0.45 A
Dimensions Landscape:
Portrait:
538.6 mm (W) x 373.9 - 483.9 mm (H) x 213.9 mm (D)
21.2 inches (W) x 14.7 - 19.1 inches (H) x 8.4 inches (D)
319.4 mm (W) x 555.1 - 593.2 mm (H) x 213.9 mm (D)
12.6 inches (W) x 21.9 - 23.4 inches (H) x 8.4 inches (D)
Monitor Stand Height Adjustment:
Adjustable Range
Tilt / Pivot / Swivel:
110 mm/4.3 inches (Landscape orientation)
38.0 mm/1.5 inches (Portrait orientation)
Up 25° Down 5° / ± 90° / 90°
Weight 5.6 kg (12.3 lbs) (with monitor stand)/3.6 kg (7.9 lbs.) (without monitor stand)
Environmental Considerations
Operating Temperature:
Humidity:
Altitude:
Storage Temperature:
Humidity:
Altitude:
5°C to 35°C/41°F to 95°F
20% to 80%
0 to 6,562 Feet/0 to 2,000 m
-10°C to 60°C/14°F to 140°F
10% to 85%
0 to 40,000 Feet/0 to 12,192 m
NOTE: Technical specifications are subject to change without notice.
