de Size and Position
h LEFT/RIGHT: Moves the image horizontally (left or right).
i DOWN/UP:
Moves the image vertically (up or down).
f NARROW/WIDE:
Increases or decreases the horizontal size of the
image.
g SHORT/TALL: Increases or decreases the vertical size of the
image.
pq Geometry Controls
The Geometry controls allow you to adjust the curvature or angle of the
sides of your display.
u IN/OUT (pincushion): increases or decreases the curvature of the
sides either inward or outward.
r LEFT/RIGHT (pincushion balance): increases or decreases the
curvature of the sides either to the left or right.
q TILT (parallelogram): increases or decreases the tilt of the sides
either to the left or right.
p ALIGN (trapezoidal):
increases or decreases the bottom of the
screen to be the same as the top.
x Color Control
9300°K/7500°K: selects one of two color settings.
R/G/B: Increases or decreases red, green or blue to adjust the color to
your desired setting.
? Tools
Provides a list of optional adjustments which include the following:
y DEGAUSS: Eliminates the build-up of stray magnetic fields which
alter the correct scan of the electron beams and affect the purity of the
screen colours, focus, and convergence. When activated, your screen
image will jump and waver a bit as the screen is demagnetised.
CAUTION:
Please allow a minimum of 20 minutes to elapse between
uses of the Degauss function.
E - 12 OSM Menus
