English - 17
Ventilation Requirements
When mounting the monitor in an enclosed space or recessed area, leave adequate room between the monitor and the
enclosure to allow heat to disperse, as shown below.
≤40°C
100 mm
100 mm
100 mm
300 mm
60 mm
NOTE The maximum environmental operating temperature of the monitor is 40 °C.
This monitor has internal temperature sensors.
NOTE If the monitor overheats, a “Warning” appears. If a “Warning” appears, stop using the monitor, turn off the power
and allow it to cool.
For more information on this function, see “Thermal Management” (page 77).
If the monitor is used in an enclosed area or if the LCD panel is covered with an acrylic protective sheet, check the
temperature around the monitor.
