NEC MultiSync LCD1560NX User Manual

English-12
Specifications
Monitor Specifications MultiSync LCD1560NX Monitor Notes
LCD Module Diagonal: 38 cm/15 inches Active matrix; thin film transistor (TFT)
Viewable Image Size: 38 cm/15 inches liquid crystal display (LCD); 0.297 mm
Native Resolution (Pixel Count): 1024 x 768 dot pitch; 250cd/m
2
white luminence,
typical; 350:1 contrast ratio, typical.
Input Signal Video: ANALOG 0.7 Vp-p/75 Ohms Digital Input: DVI
Sync: Separate sync.TTL Level
Horizontal sync. Positive/Negative
Vertical sync. Positive/Negative
Composite sync. Positive/Negative*
3
Sync on Green (Video 0.7 Vp-p and Sync. 0.3 Vp-p)*
3
Display Colours 16,194,277 Depends on display card used.
Synchronization Range Horizontal: 31.5 kHz to 60.0 kHz Automatically
Vertical: 56.2 Hz to 75.1 Hz Automatically
Viewing Angle Left/Right: ±60°
Up/Down: ±45°
Resolutions Supported 720 x 400*
1
at 70 Hz Some systems may not
640 x 480*
1
at 60 Hz to 75 Hz support all modes listed.
800 x 600*
1
at 56 Hz to 75 Hz
832 x 624*
1
at 75 Hz
1024 x 768*
2
at 60 Hz to 75 Hz
Active Display Area Horizontal: 304 mm/12 inches Dependent upon signal timing.
Vertical: 228 mm/9 inches
Power Supply 100 - 240 V ~ 50/60 Hz
Current Rating 0.4 - 0.2 A
Dimensions 344.8 mm (W) x 305.3 ~ 415.3 mm (H) X 166.0 mm (D)
13.6 inches (W) x 12.0 ~ 16.4 inches (H) x 6.5 inches (D)
Weight 4.5 kg (9.9 lbs)
Environmental Considerations
Operating Temperature: 5 °C to 35 °C
Humidity: 30% to 80%
Altitude: 0 to 3,000 m
Storage Temperature: -10 °C to +60 °C
Humidity: 10% to 85%
Altitude: 0 to 12,000 m
*1 Interpolated Resolutions: When resolutions are shown that are lower than the pixel count of the LCD module, text may appear different. This is
normal and necessary for all current flat panel technologies when displaying non-native resolutions full screen. In flat panel technologies, each dot on
the screen is actually one pixel, so to expand resolutions to full screen, an interpolation of the resolution must be done.
*2 NEC-Mitsubishi Electronics Display cites recommended resolutions at 75 Hz for optimal display performance.
*3 If your display is not showing a picture of the SOG and Composite Sync. Signal, please contact our hotline for further assistance.
NOTE: Technical specifications are subject to change without notice.
• Avoid displaying fixed patterns on the monitor for long periods of time to avoid image persistence (after-image effects).
• Get regular eye checkups.
Ergonomics
To realize the maximum ergonomics benefits, we recommend the following:
• Use the preset Size and Position controls with standard signals.
• Use the preset Colour Setting.
• Use non-interlaced signals with a vertical refresh rate between 60-75 Hz.
• Do not use primary colour blue on a dark background, as it is difficult to see and may produce eye fatigue to insufficient
contrast.

NEC MultiSync LCD1560NX Specifications

General

Display	LCD
Power requirements	100-120 V/220-240 V; 0.4 A/0.2 A
Recommended resolution	1024 x 768 at 75 Hz
Pixel pitch	0.297 mm
Response time	30 ms
Display diagonal	15 \
Display resolution	1024 x 768 pixels
Vertical scan range	56.2 - 75.1 Hz
Horizontal scan range	31.5 - 60 kHz
Display number of colors	16.78 million colors
Display brightness (typical)	250 cd/m²
Certification	CE; Energy 2000, Energy Star; FCC Class B; ISO 13406-2 (Pixel Failure Cass II); PCBC/B-mark; PCT Gost; TCO99; TÜV ERGONOMIE; TÜV GS; UL/C-UL or CSA; MPR II/ MPR III
Market positioning	-
I/O ports	1 x DVI-D; 1 x mini D-sub 15 pin.
Plug and Play	Yes
Tilt angle range	-5 - 30 °
Panel mounting interface	75 x 75 mm
Power consumption (standby)	2 W
Power consumption (typical)	20 W
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	30 - 80 %

Weight and Dimensions

Depth (without stand)	166 mm
Width (without stand)	344.8 mm
Height (without stand)	344.2 mm
Weight (without stand)	3700 g
