NEC MultiSync P462 User Manual

English-19
English
OSD (On-Screen-Display) Controls
NOTE: Some functions may not be available depending on the model or optional equipment.
PICTURE MODE
Goto Adjustment
Select
Return Close
70
50
50
50
50
50
THANK YOU FOR SAVING
THE ENVIRONMENT.
CARBON FOOTPRINT 86.0 %
Input source
Main Menu Icons
Main Menu Item
Sub Menu
Key Guide
Adjustment Settings
Remote Control
Press UP or DOWN
button to select
sub-menu.
Press SET. Press UP or DOWN,
PLUS or MINUS to select
the function or setting to
be adjusted.
Press MENU or EXIT.
Press UP or DOWN
button to select.
Press INPUT button
to decide.
Press UP or DOWN, PLUS
or MINUS button to select.
Press EXIT
Control Panel
OSD screen

NEC MultiSync P462 Specifications

General

Panel life	- h
Pixel pitch	0.53 x 0.53 mm
Response time	8 ms
Display diagonal	46 \
Display brightness	500 cd/m²
Display technology	LCD
Vertical scan range	50 - 85 Hz
Horizontal scan range	31.5 - 91.1 kHz
Display number of colors	16.78 million colors
Active display area (W x H)	1018.1 x 572.7 mm
Ethernet LAN	Yes
Multi-display supported	-
Product color	Black
Product design	Digital signage flat panel
Panel mounting interface	300 x 300 mm
Power consumption (standby)	1 W
Power consumption (typical)	155 W
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	5 - 40 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 90 %

Weight and Dimensions

Depth	103 mm
Width	1055.4 mm
Height	608.6 mm
Weight	23800 g
