NEC MultiSync UN462A User Manual

English−10
For UN462A/UN462VA/UN492S/UN492VS/UN552A:
• Use a screwdriver for fixing spacers.
• The tightening torque is 0.63 N•m or less.
Spacer
e.g. Spacer installation in multi-monitor configuration.
SPACER
8 mm
For UN492S/UN492VS:
• Use a screwdriver for fixing pins.
• The tightening torque is 0.63 N•m or less.
Pins are useful for alignment.
Pin
e.g. Pin installation in multi-monitor configuration.
PIN
8.2 mm
Pin instruction
You can fix each monitor position with pins.
When you use pins, please refer to the instructions below.
1. Connect all vertical position monitors using pins.
2. Connect each vertical monitor using pins.
For UN552S/UN552VS:
• Please locate the spacer at the edge of rear side monitor.
• Attach it by using the double-sided tape on the rear side of the spacer.
SPACER
Spacer
e.g. Spacer installation in multi-monitor configuration.
