English-37
English
INPUT DETECT Selects the method of input detection the monitor uses when more than one signal source is connected.
NOTE: When SUPER is selected within INPUT CHANGE, this function cannot be changed.
INPUT DETECT is released if HUMAN SENSOR is activated while INPUT DETECT is active.
NONE The Monitor will not search for signals at the other video input ports.
FIRST DETECT*
1,
*
2
When the current video input signal is not present, the monitor searches for a video signal from another video
input port. If a video signal is present in the other input, the monitor switches from the current video source to this
active video source automatically.
The monitor will not look for any other video signals while the current video source is present.
LAST DETECT*
1,
*
2
When the monitor is reproducing a signal from the current video source and a new second video source is supplied
to the monitor, the monitor will automatically switch to the new video source. When the current video input signal is
not present anymore, the monitor searches for a video signal from any other video input. If a video signal is present
in the other input, the monitor switches from the current video source to this active video source automatically.
CUSTOM DETECT*
1
Sets the priority of input signals. e.g. In the priorities, a signal input set to PRIORITY 1 has the highest priority.
When CUSTOM DETECT is selected, the monitor searches on preset inputs only.
NOTE: Priority of an option input signal is only available in PRIORITY3, except for a slot 2 type PC option.
If you set DisplayPort1 to Priority 1 or 2 or 3, you cannot set OPTION (slot 2 type PC option (DP)) to any priority
settings. If you set OPTION (slot 2 type PC option (DP)) to Priority 1 or 2 or 3, you cannot set DisplayPort1 to any
priority settings.
INPUT CHANGE Sets input change speed. If “QUICK” is set, speed of changing input gets faster but this setting occurs image
noise while switching signals.
The selection SUPER enables high-speed switching between two preset signals.
NOTE: It depends on the option board you use, SUPER is not available.
When “SUPER” is active, MULTI PICTURE MODE, TEXT TICKER, STILL, POINT ZOOM are not available.
TERMINAL SETTINGS
DVI MODE Selects the kind of DVI-D equipment, which is connected to the DVI input.
Select “DVI-HD” when a DVD player or computer equipment is connected which requires HDCP authentication.
Select “DVI-PC” when computer equipment is connected which does not requires HDCP authentication.
VGA MODE Selects RGB or YPbPr for VGA input.
SYNC TYPE Selects a type of sync signal of VGA (RGB).
AUTO: Automatically identifies received sync signal type.
H/V SYNC: If the input signal is H/V SYNC then displayed image is unstable with AUTO setting, please set H/V
SYNC.
SOG: If the input signal is SOG then displayed image is unstable with AUTO setting, please set SOG.
NOTE: If VGA MODE is set to YPbPr, you cannot set SYNC TYPE.
DisplayPort Selects the DisplayPort mode [1.1a] or [1.2].
DisplayPort 1.1a is selected, SST is set automatically.
DisplayPort 1.2 is selected, set SST or MST.
DisplayPort 1.2 should be selected when using Multi-Stream Transport. Multi-Stream Transport requires the
corresponding display card. Contact your supplier for limitations of this function.
NOTE: MST is not available with DisplayPort2 signal input.
BIT RATE DisplayPort 1.1a is selected at DisplayPort, HBR is set automatically.
DisplayPort1.2 and SST are selected at DisplayPort, set HBR or HBR2.
DisplayPort1.2 and MST are selected at DisplayPort, HBR2 is set automatically.
EQUALIZER Compensates for the image degradation caused by using a long cable or devices. A higher number produces
high compensation.
SLOT2 Compensates for the image degradation from the slot 2 type option DisplayPort signal.
DisplayPort1 Compensates for the image degradation from DisplayPort1 signal.
HDMI Selects MODE1 or MODE2.
MODE1: Max resolution is 3840 x 2160 (30 Hz)
MODE2: Max resolution is 3840 x 2160 (60 Hz)
VIDEO LEVEL AUTO: Automatically sets input signals by adjusting connected equipment.
RAW: For computer settings. Show all input signals of 0-255 gray levels.
EXPAND: For audio-visual equipment settings. Expands the input signals from 16-235 gray levels to 0-255 gray
levels.
NOTE: This function is available only in HDMI or DisplayPort or OPTION and is selected at INPUT SIGNAL.
RESET Resets MULTI INPUT options back to factory settings, except for INPUT DETECT (priority of input signals only),
INPUT CHANGE (INPUT1 and INPUT2), INPUT SELECT, PICTURE ASPECT and BIT RATE.
*1: When you select OPTION for multi picture input, this function depends on which option board you are using.
*2: Except for MP.
