English-20
Setting Default
BRIGHTNESS Adjusts the overall image and background brightness. Press + or - to adjust. 70
Note: When AMBIENT1 or AMBIENT2 is selected in picture mode, this function cannot changed.
CONTRAST Adjusts the image brightness in relationship to the background. Press + or - to adjust. 50
Note: The sRGB picture mode is standard and cannot be changed.
SHARPNESS Adjusts the crispness of the image. Press + or - to adjust. 50*
2
BLACK LEVEL Adjusts the image brightness in relationship to the background. Press + or - to adjust. 50
Note: The sRGB picture mode is standard and cannot be changed.
TINT Adjusts the tint of the screen. Press + or - to adjust. 50
COLOR Adjusts the color depth of the screen. Press + or - to adjust. 50*
2
COLOR TEMPERATURE Adjusts the color temperature of the entire screen. A low color temperature will make the screen 10000K
reddish. A high color temperature will make the screen bluish. If TEMPERATURE needs further
adjustment, the individual R/ G/ B/ levels of the white point can be adjusted. To adjust the
R/G/B levels, CUSTOM must be showing as the COLOR TEMP selection.
Note: The sRGB picture mode is set to a predefined 6500 K standard and cannot be changed.
COLOR CONTROL Adjusts the levels of the Red, Yellow, Green, Cyan, Blue, Magenta and Saturation. 0
Note: The sRGB picture mode is standard and cannot be changed.
GAMMA SELECTION Select a display gamma for best picture quality.
PROGRAMMABLE
Note: The sRGB picture mode is standard and cannot be changed. (except sRGB
NATIVE Gamma correction is handled by the LCD panel.
2.2 Typical display gamma for use with a PC.
2.4 Good for video (TV, DVD, etc.)
S GAMMA Special gamma for certain types of movies. Raises the dark parts and lowers the light parts
of the image (S-Curve).
DICOM SIM. DICOM GSDF curve simulated for LCD type.
PROGRAMMABLE A programmable gamma curve can be loaded using NEC software.
MOVIE SETTINGS
NOISE REDUCTION Adjusts the amount of noise reduction. Press + or - to adjust. 6*
2
TV, VIDEO1, VIDEO2, S-VIDEO inputs only
FILM MODE Selects Film mode. AUTO*
2
HDMI, DVD/HD1, DVD/HD2, SCART, VIDEO1, VIDEO2, S-VIDEO, TV* inputs only
ADAPTIVE CONTRAST Sets the level of adjustment for dynamic contrast. OFF
HDMI, DVD/HD1, DVD/HD2, SCART, VIDEO1, VIDEO2, S-VIDEO, TV* inputs only
PICTURE MODE Selects picture mode, [HIGHBRIGHT], [STANDARD], [sRGB], [CINEMA], [AMBIENT1] or STANDARD
[AMBIENT2]. See page 18.
PICTURE RESET Resets the following settings within the PICTURE menu back to factory setting: -
BRIGHTNESS, CONTRAST, SHARPNESS, BLACK LEVEL, TINT, COLOR, COLOR
TEMPERATURE, COLOR CONTROL , GAMMA SELECTION, MOVIE SETTINGS.
AUTO SETUP Automatically adjusts Screen Size, H position, V position, Clock, Clock Phase and White Level. -
VGA, RGB/HV inputs only
AUTO ADJUST H Position, V Position and Clock Phase are adjusted automatically upon power on. OFF
VGA, RGB/HV inputs only
H POSITION Controls the horizontal position of the image within the Display area of the LCD. -
Press + to move right. Press - to move left.
V POSITION Controls the vertical position of the image within the Display area of the LCD. -
Press + to move up. Press - to move down.
CLOCK Press + to expand the width of the image on the right of the screen. -
VGA, RGB/HV inputs only Press - to narrow the width of the image on the left.
CLOCK PHASE Adjusts the visual “noise” on the image. -
VGA, RGB/HV, DVD/HD1, DVD/HD2, SCART inputs only
*: The product you purchased may not have this feature. *2: depend on signal input
ADJUST
setting)
