NEC MultiSync X461UN User Manual

English-35
English
Specifications
Product Specifications
LCD Module 46" /116.8 cm diagonal
Pixel Pitch: 0.746 mm
Resolution: 1366 x 768 dots
Color: Over 16 million colors (depending on video card used)
Brightness: 700 cd/m
2
(Max.), 500 cd/m
2
(Typ.)
Contrast Ratio: 3000:1
Viewing Angle: 89° (typ) @ CR>10
Design View Distance: 1300 mm
Frequency Horizontal: 15.625/15.734 kHz, 31.5 kHz - 91.1 kHz (Analog Input)
31.5 kHz - 91.1 kHz (Digital Input)
Vertical: 50.0 - 85.0 Hz
Pixel Clock 25.2 MHz - 162.0 MHz
Viewable Size 1018.4 x 572.5 mm
Input Signal
DVI DVI-D 24pin Digital RGB DVI (HDCP)
VGA60, SVGA60, XGA60, WXGA60, SXGA60, UXGA60*
1
, 1920X1080*
1
(60Hz)
VGA 15pin Mini D-sub Analog RGB 0.7 Vp-p/75 ohm
VGA60, SVGA60, XGA60, WXGA60, SXGA60, UXGA60*
1
, 1920X1080*
1
(60Hz)
Sync Separate: TTL level (Pos./Neg.)
Composite sync on Green Video: 0.3 Vp-p Neg.
RGB/HV BNC (R,G,B,H,V) Analog RGB 0.7 Vp-p/75 ohm
VGA60, SVGA60, XGA60, WXGA60, SXGA60, UXGA60*
1
, 1920X1080*
1
(60Hz)
Sync Separate: TTL level (Pos./Neg.)
Composite sync on Green Video: 0.3 Vp-p Neg.
HDMI HDMI Connector Digital RGB HDMI
1080p*
1
, 1080i*
1
, 720p@50Hz/60Hz, 576p@50Hz, 480p@60Hz
DVD/HD1 RCA (Y, Cb/Pb, Cr/Pr) Component Y: 1.0 Vp-p/75ohm, Cb/Cr (Pb/Pr): 0.7 Vp-p/75 ohm
DVD/HD2 BNC HDTV/DVD:1080p*
1
, 1080i*
1
, 720p@50Hz/60Hz, 576p@50Hz, 480p@60Hz, 576i@50Hz, 480i@60Hz
VIDEO1 BNC/RCA Composite 1.0 Vp-p/75 ohm
VIDEO2 BNC NTSC/PAL/SECAM/4.43NTSC/PAL60
S-VIDEO Mini DIN 4 pin S-VIDEO Y: 1.0 Vp-p/75 ohm C: 0.286 Vp-p/75 ohm (NTSC), 0.3 Vp-p/75 ohm (PAL/SECAM)
NTSC/PAL/SECAM/4.43NTSC/PAL60
Output Signal
RGB/HV BNC (R,G,B,H,V) Analog RGB 0.7 Vp-p with 75 ohm terminated
Separate HV sync: TTL level (Posi / Nega)
DVD/HD2 BNC Component Y: 1.0 Vp-p/75ohm, Cb/Cr (Pb/Pr): 0.7 Vp-p/75 ohm
VIDEO1/VIDEO2 BNC Composite 1.0 Vp-p with 75 ohm terminated
AUDIO
AUDIO RCA (L/R) X2 Analog Audio Stereo L/R 0.5 Vrms
Input STEREO Mini Jack
HDMI Connector Digital Audio PCM 32, 44.1, 48 KHz (16/20/24bit)
AUDIO RCA (L/R) Analog Audio Stereo L/R 0.5 Vrms
Output
Control RS-232C In: 9 Pin D-sub
RS-232C Out: 9 Pin D-sub (with daisy chain)
LAN: RJ-45 10/100 BASE-T
Remote IN: Stereo Mini jack 3.5
Remote OUT: Stereo Mini jack 3.5
TV*
2
Antenna: F-connector Impedance 75 ohm
Channel Coverage: VHF: 2 - 13 ch
UHF: 14 - 69 ch
CATV: 1 - 130 ch
ATSC (8VSB): 2 - 69 ch
64/256 QAM : 1 - 135 ch
Power Supply 3.6 - 1.45 A @ 100-240VAC, 50/60Hz
Operational Environment Temperature: 5 - 40°C (Default brightness), 5 - 20°C (Max brightness)
Humidity: 20 - 80% (without condensation)
Altitude: 0 - 3000 m
Storage Environment Temperature: -20 - 60°C
Humidity: 10 - 90% (without condensation)/ 90% - 3.5% x (Temp - 40°C) regarding over 40°C
Dimension 1025.7 (W) x 579.8 (H) x 128.1 (D) mm (without stand)
Weight 29.3 Kg (without stand)
VESA compatible arm mounting interface 300 mm x 300 mm (M6, 4 Holes)
Complied Regulatory and Guidelines UL60950-1/CSA C22.2 No.60950-1/ TUV-GS/EN60950-1
FCC-A/DOC-A/EN55022-A/EN55024/EN61000-3-2/EN61000-3-3/CE/GOST-R
Power Management VESA DPM
Plug & Play VESA DDC2B, DDC/CI
Accessories Setup manual, Power Cord, Video Signal cable, Stereo Mini plug cable (3.5
), Clamp x 3,
Screw x 9, CD-ROM, Thumbscrew for stand x 2, Cable cover
NOTE: Technical specifications are subject to change without notice. *1: Compressed image *2: The product you purchased may not have this feature.
