Installation

The Installation Set-Up Instruction chapter covers how to install the projector

and gives you the details about the relative position of the projector and the

screen.

The Projection Configuration Change chapter gives you the procedures for

adjustments such as image polarity change, proper adjustment of the focus

rings and CRT angle adjustment. You must reconfigure the projector for your

application when it differs from the factory setting.

CONTENTS

INSTALLATION SET-UP INSTRUCTION ............................................3

Before Installation .................................................................................................. 3

Carrying the Projector............................................................................................ 3

Note on Installation................................................................................................ 4

XG75A ....................................................................................... 5

Projection Distance and Screen Size for Ceiling Mount ...................................... 5

Projection Distance and Screen Size for Desk Top ............................................. 6

Projection Distance and Screen Size for Rear Projection.................................... 7

XG110LC/XG135LC ........................................................................ 8

Projection Distance and Screen Size for Ceiling Mount ...................................... 8

Projection Distance and Screen Size for Desk Top ............................................. 9

Projection Distance and Screen Size for Rear Projection.................................. 10

PROJECTION CONFIGURATION CHANGE ........................................ 11

Before Installation Change ................................................................................... 11

Removing and Reinstalling Top Cover ................................................................. 13

Scan Reversal ...................................................................................................... 14

Removing and Reinstalling Front Panel ............................................................... 15

Screen Size Change (Adjusting Focus Rings and CRT Angle) for XG75A............. 15

Screen Size Change (Adjusting Focus Rings and CRT Angle) for XG110LC/XG135LC..... 17

Lens Focus Adjustment........................................................................................ 19

Important

When installing the projector, follow the warnings and cautions in the manual.

Failure to observe this precaution could result in electric shock or injury.

If installing the projector on the ceiling, use only optional ceiling kits (two

types) supplied by the manufacturer. Refer to the manual included with the

optional ceiling kit for ceiling installation. When ordering the kit, specify the

part name, PG CMKIT-F or PG CMKIT.

NEC MultiSync XG110LC Installation Manual

Other manuals for NEC MultiSync XG110LC
