NEC NP-M271X - Adjusting Picture Size and Position

18
2. Projecting an Image (Basic Operation)
 Adjusting the Picture Size and Position
Usetheadjustabletiltfoot,thezoomfunctionorthefocusringtoadjustthepicturesizeandposition.
Inthischapterdrawingsandcablesareomittedforclarity.
Adjustingthethrowangle(theheightofanimage)
[Tiltfoot](→page19)
Adjustingtheleftandrighttiltofanimage
[Rearfoot](→page19)
Finelyadjustingthesizeofanimage
[Zoomlever](→page20)
Adjustingthefocus
[Focusring](→page20)
Adjustingthekeystonecorrection[KEYSTONE]*(→page21)
AutomaticKeystoneCorrectionfunctionisturnedonatthetimeofshipment.
Toperformkeystonecorrectionmanually,see“6.CorrectingKeystoneDistortionManually”onpage21.
