3.46 [ 098-198. PIP/PICTURE BY PICTURE SET ]
Sets the picture in picture or picture by picture.
Command
03h B1h 00h 00h 03h C5h <DATA01> <DATA02> <CKS>
Data part
Item Description
DATA01 Target
00h MODE
01h START POSITION
02h SUB INPUT
DATA02 Setting value (when DATA01 is 00h "Mode")
00h PIP
01h PICTURE BY PICTURE
Setting value (when DATA01 is 01h "START POSITION")
00h TOP-LEFT
01h TOP-RIGHT
02h BOTTOM-LEFT
03h BOTTOM-RIGHT
Sub input setting value (when DATA01 is 02h "SUB INPUT")
Information
For the values of the Sub input setting value, see the Appendix "Supplementary Information by Command".
