NEC NP4000 - NP4001 Throw Distance and Screen Size Values

2. Installation and Connections
24
NP4001 Throw Distance and Screen Size Values
Screen Size NP06FL NP07ZL NP08ZL
Diagonal Width Height (B)
Distance (A)
[inches] [m] [inches] [m] [inches] [m] [inches] [m] [inches] [m] [inches] [m]
40 1.02 34.3 0.87 20.5 0.52 45.4 - 61.8 1.15 - 1.57 60.9 - 81.0 1.55 - 2.06
50 1.27 42.9 1.09 25.6 0.65 33.5 0.85 57.2 - 77.7 1.45 - 1.97 76.7 - 101.9 1.95 - 2.59
60 1.52 51.6 1.31 30.7 0.78 40.5 1.03 69.0 - 93.6 1.75 - 2.38 92.5 - 122.8 2.35 - 3.12
67 1.70 57.6 1.47 34.3 0.87 45.4 1.15 77.3 - 104.7 1.96 - 2.66 103.6 - 137.4 2.63 - 3.49
72 1.83 61.9 1.58 36.8 0.94 48.9 1.24 83.2 - 112.7 2.11 - 2.86 111.5 - 147.9 2.83 - 3.76
80 2.03 68.5 1.74 41.3 1.05 54.5 1.38 92.7 - 125.4 2.35 - 3.19 124.2 - 164.6 3.15 - 4.18
84 2.13 71.9 1.83 43.4 1.10 57.3 1.46 97.4 - 131.8 2.47 - 3.35 130.5 - 172.9 3.31 - 4.39
90 2.29 77.1 1.96 46.5 1.18 61.5 1.56 104.5 - 141.3 2.65 - 3.59 140.0 - 185.4 3.56 - 4.71
100 2.54 85.8 2.18 51.6 1.31 68.5 1.74 116.3 - 157.2 2.95 - 3.99 155.8 - 206.3 3.96 - 5.24
120 3.05 102.8 2.61 61.8 1.57 82.5 2.10 140.0 - 189.0 3.56 - 4.80 187.4 - 248.1 4.76 - 6.30
150 3.81 128.7 3.27 77.2 1.96 103.5 2.63 175.5 - 236.7 4.46 - 6.01 234.9 - 310.7 5.97 - 7.89
180 4.57 154.3 3.92 92.5 2.35 124.5 3.16 211.0 - 284.4 5.36 - 7.22 282.3 - 373.3 7.17 - 9.48
200 5.08 171.7 4.36 102.8 2.61 138.5 3.52 234.6 - 316.2 5.96 - 8.03 313.9 - 415.1 7.97 - 10.54
210 5.33 180.3 4.57 107.9 2.74 246.4 - 332.1 6.26 - 8.44 329.7 - 436.0 8.38 - 11.07
240 6.10 206.0 5.24 123.4 3.13 281.9 - 379.8 7.16 - 9.65 377.2 - 498.6 9.58 - 12.66
261 6.63 224.1 5.69 134.2 3.41 306.8 - 413.2 7.79 - 10.50 410.4 - 542.4 10.42 - 13.78
270 6.86 231.8 5.89 138.8 3.52 317.4 - 427.5 8.06 - 10.86 424.6 - 561.2 10.79 - 14.25
300 7.62 257.1 6.53 154.3 3.92 352.9 - 475.2 8.96 - 12.07 472.1 - 623.8 11.99 - 15.85
350 8.89 300.0 7.62 180.0 4.57 412.0 - 554.8 10.47 - 14.09 551.2 - 728.2 14.00 - 18.50
400 10.16 342.9 8.71 205.9 5.23 471.2 - 634.3 11.97 - 16.11 630.2 - 832.6 16.01 - 21.15
450 11.43 385.8 9.80 231.6 5.88 530.3 - 713.8 13.47 - 18.13 709.3 - 937.0 18.02 - 23.80
500 12.70 428.7 10.89 257.1 6.53 589.5 - 793.3 14.97 - 20.15 788.4 -
1041.4
20.02 - 26.45
Screen Size NP09ZL NP10ZL
Diagonal Width Height (B)
Distance (A)
[inches] [m] [inches] [m] [inches] [m] [inches] [m] [inches] [m]
40 1.02 34.3 0.87 20.5 0.52 75.7 - 155.0 1.92 - 3.94 151.7 - 289.8 3.85 - 7.36
50 1.27 42.9 1.09 25.6 0.65 95.7 - 194.7 2.43 - 4.95 190.9 - 363.5 4.85 - 9.23
60 1.52 51.6 1.31 30.7 0.78 115.6 - 234.5 2.94 - 5.96 230.2 - 437.3 5.85 - 11.11
67 1.70 57.6 1.47 34.3 0.87 129.6 - 262.4 3.29 - 6.66 257.7 - 488.9 6.55 - 12.42
72 1.83 61.9 1.58 36.8 0.94 139.6 - 282.3 3.55 - 7.17 277.3 - 525.8 7.04 - 13.36
80 2.03 68.5 1.74 41.3 1.05 155.6 - 314.1 3.95 - 7.98 308.8 - 584.9 7.84 - 14.86
84 2.13 71.9 1.83 43.4 1.10 163.6 - 330.0 4.15 - 8.38 324.5 - 614.4 8.24 - 15.60
90 2.29 77.1 1.96 46.5 1.18 175.5 - 353.9 4.46 - 8.99 348.0 - 658.6 8.84 - 16.73
100 2.54 85.8 2.18 51.6 1.31 195.5 - 393.6 4.97 - 10.00 387.3 - 732.4 9.84 - 18.60
120 3.05 102.8 2.61 61.8 1.57 235.4 - 473.2 5.98 - 12.02 465.9 - 880.0 11.83 - 22.35
150 3.81 128.7 3.27 77.2 1.96 295.3 - 592.6 7.50 - 15.05 583.7 -
1101.3
14.83 - 27.97
180 4.57 154.3 3.92 92.5 2.35 355.2 - 711.9 9.02 - 18.08 701.5 -
1322.6
17.82 - 33.59
200 5.08 171.7 4.36 102.8 2.61 395.2 - 791.5 10.04 - 20.10 780.0 -
1470.2
19.81 - 37.34
210 5.33 180.3 4.57 107.9 2.74 415.1 - 831.3 10.54 - 21.11 819.3 -
1543.9
20.81 - 39.22
240 6.10 206.0 5.24 123.4 3.13 475.0 - 950.6 12.07 - 24.15 937.1 -
1765.3
23.80 - 44.84
261 6.63 224.1 5.69 134.2 3.41 517.0 -
1034.1
13.13 - 26.27
1019.6
-
1920.2
25.90 - 48.77
270 6.86 231.8 5.89 138.8 3.52 534.9 -
1069.9
13.59 - 27.18
1054.9
-
1986.6
26.80 - 50.46
300 7.62 257.1 6.53 154.3 3.92 594.8 -
1189.3
15.11 - 30.21
1172.8
-
2207.9
29.79 - 56.08
350 8.89 300.0 7.62 180.0 4.57 694.7 -
1388.2
17.64 - 35.26
1369.1
-
2576.8
34.78 - 65.45
400 10.16 342.9 8.71 205.9 5.23 794.5 -
1587.1
20.18 - 40.31
1565.5 - 2945.7
39.76 - 74.82
450 11.43 385.8 9.80 231.6 5.88 894.3 -
1786.0
22.72 - 45.37
1761.9 - 3314.6
44.75 - 84.19
500 12.70 428.7 10.89 257.1 6.53 994.1 -
1984.9
25.25 - 50.42
1958.2 - 3683.4
49.74 - 93.56
