2. Installation and Connections
Connecting Your DVD Player with Component Output
A component signal will be automatically displayed. If not, from the menu, select [SETUP] → [OPTIONS(1)] →
[SIGNAL SELECT] → [COMPUTER1], and then place a check mark in the Component radio button.
• Select the source name for its appropriate input connector after turning on the projector.
Input connector
SOURCE button on the projector
cabinet
Button on the remote control
COMPUTER 1 IN COMPUTER1 (COMPUTER 1)
NOTE: Refer to your DVD player’s owner’s manual for more information about your DVD player’s video output requirements.
AUDIO IN
L R
AUDIO OUT
L R
Component
Y Cb Cr
COMPUTER 1 IN
AUDIO IN
Audio cable (not supplied)
15-pin - to - RCA (fe-
male) 3 cable adapter
(ADP-CV1E)
Component video RCA3
cable (not supplied)
DVD player
Audio Equipment
