NEC PA500X
SPECIAL CHARACTERISTICS
3D Stacking, AMX Beacon, Crestron RoomView, DICOM
Simulation, Digital 3D Reform™, Direct Power-Off Function, Edge
Blending Function (08.2011), FREE DisplayNote Presenter, Free
Tilt, Geometric Correction, Help Function, Hollywood Quality Video
Processing for best image quality, Keystone Correction (H=±40°,
V=±30°), LAN, Lens Shift (vertical +0.5 max/-0.1 max, horizontal ±
0.3 max.), Manual Wall Color Correction, Multi-Screen
compensation mode, NaViSet Administrator 2, Optional User Logo,
OSD with 27 languages, Password Security System, PIP/Side by
Side, HDMI - Input, PJ LINK, Plug&Play W-LAN Option, Remote
Desktop, RS-232 Control, Source Select with Beep Function,
Stacking Function, Timer-Function, USB Viewer, Virtual Remote
for direct PC control, Windows 7 Network Projector, Windows
Media Connect Function, Windows Network Drive, 100%
recyclable packaging, Downloadable manuals, RoHs compliant,
Unique NEC Necycle Bio-Plastic cable cover option, ErP compliant,
Intelligent Power Management, WEEE
Energy Efficiency Intelligent Power Management
Ecological
Materials
100% recyclable packaging; Downloadable
manuals; Unique NEC Necycle Bio-Plastic
cable cover option
Ecological
Standards
RoHs compliant; ErP compliant; WEEE
Technical Specification NEC PA500X
Display
3 x 2 cm (0.79") p-Si inorganic LCD Panel with MLA
Native Resolution
1024 x 768 (XGA)
Contrast Ratio
1
2000:1
Brightness
1
5000 ANSI Lumen (approx. 80% in Eco Mode), with std. optional lense
Lamp
330 W UHP AC (264 W UHP AC Eco Mode)
Lamp Life [hrs]
3000 (4000 Eco Mode)
Lens
6 optional bayonet lenses
Projection Factor
depending on lens selection (std. option NP13ZL at 1.5-3.02:1)
Projection Distance [m]
0.5 (NP11FL) - 76.4 (NP15ZL)
Screen Size (diagonal) [cm] / [inch]
Minimum: 76 / 30"; Maximum: 1,270 / 500"
Zoom
Manual (x2 with optional lens NP13ZL)
Focus Adjustment
Manual
Supported Resolutions
1920x1200 (WUXGA) - 640x480 (VGA); 1080i/60; 1080p/60; 1080i/50; 1080p/50;
720p/60; 720p/50; 576i/50; 576p/50; 480p/60; 480i/50
Frequency
Horizontal: 15–108 kHz (RGB: 24 kHz– 108 kHz); Vertical: 48 – 120 Hz
CONNECTIVITY
RGB (analog)
Input: 2 x Mini D-sub 15-pin, compatible to component (YPbPr); 1 x 5BNC, shared
with Component Signal (YPbPr)
Output: 1 x Mini D-sub 15 pin
Digital
Input: 1 x DisplayPort; 1x HDMI™ (V.1.3) supporting HDCP
Video
Input: 1 x RCA
S-Video
Input: 1 x Mini DIN 4-pin
Audio
Input: 1 x DisplayPort Audio support; 1 x HDMI audio support; 3 x 3.5 mm Stereo
Mini Jack for Computer analog; 1 x RCA Stereo for Video and S-Video
Output: 1 x 3.5 mm Stereo Mini Jack (variable)
PC Control
Input: 1 x D-Sub 9 pin (RS-232), Network
USB
2 x Type A (USB 2.0 high speed)
Video Signals
PAL; PAL60; NTSC; SECAM; NTSC 4.43; PAL-N; PAL-M
REMOTE CONTROL
Remote Control
Aspect Ratio; Audio Control; Auto Adjust; DisplayPort; Freeze-function; HDMI;
Help-function; ID set; Lamp Mode Control; Magnify-function; Page (up, down);
Picture Adjust; Picture Mute; Power (On-OFF); Select (up, down, left, right); Source
Select
ELECTRICAL
Power Supply
100-240 V AC; 50 - 60 Hz
Power Consumption [W]
443 Normal Mode; 356 Eco Mode; 6 Network Stand-By Mode; 0.2 Power Savings
Mode
MECHANICAL
Dimensions (W x H x D) [mm]
499 x 144 x 359 (without lens and feet)
Weight [kg]
7.7
Fan Noise [dB (A)]
31 / 38 (Eco / Normal)
ERGONOMICS
Safety and Ergonomics
CE; ErP; TÜV GS; RoHS
Speakers [W]
1 x 10 (mono)
WARRANTY
Projectors
3 years pan-European service
Lamp
6 months, max. 1000 hrs
SHIPPING CONTENT
Shipping Contents
Projector; IR Remote Control (RD - 455E); Mini D-SUB Signal Cable; Power Cord;
Users Manual on CD-ROM; Network Set-up Guide; Quick Setup Guide
OPTIONAL ACCESSORIES
Optional Accessories
Cable Cover (NP02CV); Lamp (NP21LP); Wireless LAN module NP02LM2
(Europe), NP02LM3 (Russia)
Lenses
NP11FL (0.8:1); NP12ZL (1.19-1.56:1); NP13ZL (1.5-3.02:1); NP14ZL (2.97-4.79:1);
NP15ZL (4.7-7.2:1)
1
Compliance with ISO21118-2005
