To adjust the image
Image Adjustments for D-SUB(PC) Mode/Component Mode
1
3
Press MENU and the main menu screen displays.
Within the menu, press 5,6,3,4 to navigate through the options
or adjust an option, press OK to confirm a selection and activate it.
Press 3/4to select Display menu, press 6 to access the menu.
2
Note
=
Only in D-Sub and Component mode, the Display menu can be accessed.
=
Only in D-Sub mode, the Auto Adjust can be activated.
Option
Description
H.Position
V. Position
Phase
Auto Adjust
(PC mode only)
Moves the image on the screen left or right.
Moves the image on the screen up or down.
Improves the focusing of a stable image.
Selects and activates to start auto adjustment. The television automatically adjusts the image
settings, such as position and phase.
Before adjusting the image, make sure that you select the correct source (D-Sub or YPbPr).
Video Audio Setup Rate System Display
H.Position
Phase
AutoAdjust
48%
60%
42%
V.Position
27
To Next Page
