1
3
4
5
2
6
7
8
9
10 11 12
1 Large LED Lamp
This is a multi colour lamp that flashed when you receive an incoming call,
or when a voice mail message has been left.
2 Screen Soft Keys
These keys are used to access the 4 options listed on the bottom row of
the LCD screen. These options change depending on the feature you are
currently using.
3 Flexible Programming Keys
These keys are programmable to be assigned different functions of the
phone system. Most commonly used for line keys, and one touch access
to dial internal extensions.
4 Recall Key
The recall key is used for accessing Telstra network features ie call waiting,
3 way chat etc.
5 Feature Key
The Feature key is used to access administrator features of the system,
only available to NEC proprietary handsets.
6 Microphone Key
The Mic key is used to toggle the external microphone on the handset
(located in the bottom right corner of the phone). When the LED light is
red, the microphone is active.
7 Menu Key
The Menu key is used for accessing you handsets call history, directory
and personal settings.
8 Answer Key
Used when answering multiple calls. If you are currently on a call, pressing
the Answer Key will place the current call on hold, and answer the next
incoming caller with the touch of one key.
9 Navigator Dial
Pressing the navigator dial up or down, controls the volume of the
handset. Pressing the navigator dial to the left or right accesses the redial
list and the speed dial directory respectively.
10 Hold Key
Places incoming or outgoing calls on hold.
11 Transfer Key
Transfers external callers to another destination.
12 Speaker Key
The Speaker key is used to answer calls in hands free.
