Installation
B = Vertical distance between lens center
and screen center.
C = Throw distance.
D = Vertical distance between lens center
and bottom of screen (top of screen
for ceiling application).
= Throw angle.
α
Screen Size
(B)
(C)
D
(WIDE)
α
α
Diagonal (A) Width Height Wide Tele Wide Tele
inch mm inch mm inch mm inch mm inch mm inch mm inch mm degreedegree
100 2540 80 2032 60 1524 39 990 156 3962 172 4368 9 228
14.0 12.8
120 3048 96 2438 72 1829 47 1188 187 4754 206 5242 11 274
14.0 12.8
150 3810 120 3048 90 2286 58 1486 234 5943 258 6553 13 343
14.0 12.8
180 4572 144 3658 108 2743 70 1783 281 7131 310 7863 16 411
14.0 12.8
200 5080 160 4064 120 3048 78 1981 312 7923 344 8737 18 457
14.0 12.8
240 6096 192 4877 144 3658 94 2377 374 9508 413 10484 22 548
14.0 12.8
270 6858 216 5486 162 4115 105 2674 421 10697 464 11795 24 617
14.0
12.8
300 7620 240 6096 180 4572 117 2971 468 11885 516 13105 27 685
14.0 12.8
* This table is for user’s reference only.
*The values in the tables are design values and may vary.
Projection Image Size from 30” to 300” (0.76 to 7.62 meters).
Models: NP-V332W, NP-V302W
Screen Size
(B)
(C)
D
(WIDE)
α
α
Diagonal (A) Width Height Wide Tele Wide Tele
inch mm inch mm inch mm inch mm inch mm inch mm inch mm degreedegree
30 762 25 646 16 404 10 253 39 1002 43 1099 2 51 14.2 13.0
40 1016 34 862 21 538 13 337 53 1335 58 1465 3 68 14.2 13.0
60 1524 51 1292 32 808 20 506 79 2003 86 2197 4 102 14.2 13.0
70 1778 59 1508 37 942 23 591 92 2337 101 2563 5 119 14.2 13.0
80 2032 68 1723 42 1077 27 675 105 2671 115 2929 5 136 14.2 13.0
90 2286 76 1939 48 1212 30 759 118 3005 130 3296 6 153 14.2 13.0
100 2540 85 2154 53 1346 33 844 131 3339 144 3662 7 171 14.2
13.0
120 3048 102 2585 64 1615 40 1012 158 4006 173 4394 8 205 14.2 13.0
150 3810 127 3231 79 2019 50 1265 197 5008 216 5493 10 256 14.2 13.0
180 4572 153 3877 95 2423 60 1518 237 6009 259 6591 12 307 14.2 13.0
200 5080 170 4308 106 2692 66 1687 263 6677 288 7323 13 341 14.2 13.0
